5kw low rpm hydro generator/PMG Alternator for sale

Product Overview

Description

1.    Rare earth permanent magnetic for rotor.

2.    100%COPPER wire winding for stator.

3.    Brushless and easy maintaince.

4.    Digital inverter to insure stable voltage and frequency.

5.    High efficiency and can save 20% fuel than normal generator

6.    Also this new design CT alternator is more compact and it can help you to save sea freight. For example, 816sets CT-3KW can be put in 20 ft.

7.Reliable quality, 100% warranty, variable speed but stable frequency and voltage





Model	CT-5KW
Rated voltage	230(V)
Rated current	21.7(A)
Rated power	5(KW)
Speed	2000-3200rpm
Freqyency	50/60(Hz)
Output wave	pure sine wave,Waveform distortion rate≤1.5%
Stator	100% copper winding
Rotor	Rare earth permanent magnetic
GW	23.0(Kg)
NW	22.5(Kg)
Foot	182×90(MM)
Height of center	126(MM)
screw	M12
Axis dimeter	32(MM)
Packing	335×326×261(MM)
Marks	PMA+INVERTER=2 IN 1 complete set



100% COPPER WIRE

Indication Panel
