SF 101(10A) smart Intelligent digital temperature controller for chiller refrigeration include NTC sensors
- Category: >>>
- Supplier: Zhongshan Shangfang Instrument Meter Co. Ltd.
Share on (60133976641):
Product Overview
Description
SF-101(10A) Intelligent digital temperature controller for chiller refrigeration include NTC sensors
Product Description
Features
Temperature Display
Temperature Control
Light Control
Value Storing
Parameter Locking
Self Testing
Technical Data
Range of temperature displayed:-45℃~100℃
Range of set temperature:-45℃~45℃
Accuracy:±1℃
Compressor: N.O. 10A/250VAC
Light: N.O. 6A/250VAC
Dimension:77(Length)×35(Width)×60(Depth)mm
Mounting hole dimension:71(Length)×29(Width)mm
Parameters
| Parameter | Function | Set range | Default |
| E1 | Lower setpoint limit | -45℃~Set temp. | -35℃ |
| E2 | Higher setpoint limit | Set temp.~45℃ | 20℃ |
| E3 | Temp.hysteresis | 1~10℃ | 4℃ |
| E4 | Comp.start delay time | 0~10Min | 2Min |
| E5 | Offset on room temp. | -20~20℃ | 0℃ |
