                    Carding Machinery For Animal Fiber



Product Description



Cashmere Dehairing Machine is suitable for cashmere, camel, yak and other raw materials. Main role is to open the wool, remove the dust, remove coarse wool to make qualified cashmere wool.

  • Cylinder transmission using centrifugal friction clutch and v-belt for driving ,with reliable structure ,smooth start ,the motor sit on the rack ,no need of anchor bolts.
  • Randolph transmission using electromagnetic clutch, electromagnetic switch outside the shield , operating easier safer and more effective then before.
  • The bottom is 6mm closer then before ,reduce the loss of the short velvet
  • the board is 42mm width ,reduce the loss of fiber
  • Feed roller using spring-loaded , more convenience and feeding uniform.

                  Specifications and technical parameters





Name

Cashmere carding machinery

Model number

A186

Machine width

1020mm

Dimensions(LWH)

3300mm*1800mm*1800mm

Cylinder working speed

180-210r\\min

Randolph working speed

10-12r\\min

Licker working speed

500-600r\\min

The chooper frequency

1200\\min

Cover root number

2-4r\\min

The main motor

YQ-DJ-2.8-960(2.8kw 960r/min)

Weight

4100Kg

Output

5-6Kg\\h

Fiber loss

<2%
