Factory Price ! High Quality lathe Machine from China

Share on (60142759383):


Price:$2,000.00

Quantity:


Product Overview

Description


HIGH QUALITY MACHINT TOOLS LATHE MACHINE





Product Description

  PRODUCT FEATURES


*THE SURFACE OF THE BEDWAYS IS SUPERSONIC FREQUENCY HARDENED.
*GEARS PRECISELY GROUND TO REDUCE NOISE.
*SPINDLE SYSTEM IS OF HIGH RIGIDITY AND PRECISION.
*RAPID FEED STRUCTRUE IS AVAILABLE ON APRON.


DIFFERENCE BETWEEN CH AND CHF SERIE


*THE FEED BOXES OF THE TWO MODLE ARE DIFFERENCE.
*CH SERIES NEED CHANGE GEARS AND THE CHF SERIES DON'T NEED IN THREAD MACHINING.



ModelC6236HC6240HC6250HC6260H
CH6236FCH6240FCH6250FCH6260F
CAPACITYMax.swing over bed360mm400mm500mm600mm
Max.swing over cross slide190mm230mm330mm330mm
Max.swing over gap520mm560mm660mm760mm
Effective length of gap200mm
Center Distance750\\1000\\1500\\2000mm
Bed Width360mm
HEADSTOCKSpindle hole52mm
Spindle noseISO-C6
Spindle taperMT6
Spindle speed(Number)(9steps)40-1400rpm
FEEDSLongitudinal feeds range0.0832-4.66mm/r
Cross feeds range0.048-2.69mm/r
Metric threads range19kinds 0.25-14mm
Inch threads range49kinds 2-40inch
Moudle threads range11kinds 0.5-3.5mπ
CARRIAGEMax.travel of top slide95mm
Max.travel of cross slide180mm200mm250mm250mm
Max.size of toolshank20*20mm2
TAILSTOCKDia.of tailstock sleeve65mm
Taper of tailstock sleeveMT4
Max.travel of tailstock140mm
MOTORMain drive motor4KW5.5KW7.5KW
 Coolant pump motor125W
PACKING
L*W*H
Center Distance(750mm)225*115*175cm
Center Distance(1000mm)245*115*175cm
Center Distance(1500mm)295*115*175cm
Center Distance(2000mm)345*115*175cm
N.W/G.WCenter Distance(750mm)1350/1750kg1400/1800kg1500/1900kg1600/2000kg
Center Distance(1000mm)1450/1850kg1500/1900kg1600/2000kg1700/2100kg
Center Distance(1500mm)1600/2000kg1650/2050kg1750/2150kg1900/2300kg
Center Distance(2000mm)1750/2150kg1800/2200kg1900/2300kg2050/2450kg
***STANDARD ACCESSORIES
3-jaw & 4-jaw
Steady rest & follow rest
Face plate
Drive plate
Thread-cutting dial
Longitudinal touch stop
Work lamp
Coolant system
Full-length splash guard
Foot brake and brake ribbon
Change gears
Dead centre and centre sleeve
Oil gun
Paddings
One whole set spanner
***OPTIONAL  ACCESSORIES
Rapid travel
Live centre
Digital readouts(SINO)
CE-conformity(Chuck guard and Toolpost guard)
Magnetoelectrical brake
Taper cutting function



CH  01C6240H-1500IMG_20120926_084207IMG_20120926_084141IMG_20120926_084032IMG_20120926_08413021IMG_20120427_140729IMG_1371IMG_20120925_173509IMG_20120925_173527DSCF0172

IMG_20120925_173758IMG_20120926_084032



FAQ



How about your machine quality?We are worry about the quality.


Brillante is a mature brand in CHINA,through our many years research in technology,our design including structure and detailed sercurity and precision has enhanced greatly,and can match all the CE standard or more strict standard.Our machines distribute worldwide to about 50 countries where there are metal plate industry ,there are Brillante machines.And where there are our machines,there are good reputation and terminal user satisfaction.


Whether the machine price can be more discount


Brillante always provide high quality machine,as we know ,oversea market is more important and difficult than domestic market because of communication time costing after sales,So always,our machine has enough qaulity standard to make sure the machine can work more than the real warranty period.In this way ,we will save a lot and think in advance for the clients.
Actually Brillante also think about our price level,we are sure to provide quality=price and pice=quality ,the matched price and acceptable for the clients and durable for our machines.We welcome your negotiate with us and get a good satisfaction.
How about your manufactory in CHINA


Brillante located in HAIAN CITY,NANTONG,JIANGSU province who is the leading area in China and also in the worldwide as the center of the metal plate solution machines,We have worked about 10 years in this area and totally have about 150 staffs.Rich experience in this field with professional technical supporting and oriented service.


We welcome your visit to us any time.


Brillante provide oriented after-sales service including the oversea engineers trainning available and also international dealer center for any emergency guidance.We have established worldwide network to guarantee our timely response for your any demand no matter where are you.
We welcome engineers from your side to learn the technical design and normal maintenance here,this will help your easy in understanding and helpful if you need to be our dealer.
However,donto worry,we have our company own CD/Manual to show you along with the machine.So you can learn this from the existing docments to deepen your knowledge and understanding.
Anyhow there are another way is through internet video face to face for machine teaching, because of the high development in internet,the world has become smaller and you can easy cath us if any assistance needed.
Through all the ways,we will guarantee the service quality and ensure you will be well helped anytime anywhere.
