Электростатическая двухпистолетная машина для порошкового покрытия ESP 101
- Category: >>>
- Supplier: Weifang Galin Powder Coating Equipment Co. Ltd.
Share on (60147891005):
Product Overview
Description
Product Description
electrostatic manual powder coating machine ESP 101-double gun
ESP101 technical parameters
Every control panel Electrical data
Nominal input voltage | 220V (100V-240VAC) |
Frequency | 50/60 Hz |
Input power | 50 VA |
Rated output voltage (to gun) | 12~18VPP |
Rated output current (to gun) | 1.2A |
Protection type | IP54 |
Temperature rang | +10o C to +40o C (+50o F to +104o F) |
Solenoid Valve Volatge | 24VDC |
Gun output voltage | 0-100KVDC |
Gun output current | 0-100μA |
Pneumatical data
MAX.input pressure | 8bar |
MIN.input pressure | 5bar |
Output pressure | 0~8bar |
Max.water vapor content of the compressed air | 1.3g/m³ |
Max.oil vapor content of the compressed air | 0.1mg/m³ |
Max.compressed air consumption | 19Nm³/h |
Gun paramter
Input | 12~18VPP |
Voltage Frequency | Around 25KHZ |
Input Current | 1.2A |
Output Voltage | 0~100KV DC |
Max.Output powder volume | Around 600G/MIN |
Gun cable | 4 M |
Gun weight | 490g |
Dimensions
Width | 48mm |
Depth | 59mm |
Height | 89mm |
Weight | 48kg |
Container Capacity | 55l |
Packing list
control panel with all kindls of connectors | 2set |
Cart with filter | 1 set |
Manual coating gun with round nozzle with cable | 2 set |
powder hose | 2 set |
air tube | 2 set |
304 stainless hopper | 1 set |
injector | 2 set |
Related powder coating machine :
electrostatic manual powder coating machine PGC-1
Electrical data
Nominal input voltage | 100V-240VAC |
Frequency | 50/60 Hz |
Connected load | 50 VA |
Rated output voltage (to gun) | 10 V |
Rated output current (to gun) | 1.2 VA |
Protection type | IP54 |
Temperature rang | +10o C to +40o C (+50o F to +104o F) |
Solenoid Valve Volatge | 24VDC |
Gun output voltage | 0-100KVDC |
Gun output current | 0-100μA |
Pneumatical data
MAX.input pressure | 10bar |
MIN.input pressure | 5bar |
Max.water vapor content of the compressed air | 1.3g/m³ |
Max.oil vapor content of the compressed air | 0.1mg/m³ |
Max.compressed air consumption | 19Nm³/h |
Dimensions
Width | 590mm |
Depth | 710mm |
Height | 1070mm |
Weight | 59kg |
Container Capacity | 50l |
Gun weight | 480g |
HVM 2078
HVM 2078 Technical Parameters
Electrical data
Input Voltage | AC 220V/50HZ |
Frequency | 40VA |
Magnetic Control Voltage | DC24V |
Pneumatical data
Input Pressure | 8bar |
Air Consumption | 19Nm³/h |
Max.water vapor content of the compressed air | 1.3g/m³ |
Max.oil vapor content of the compressed air | 0.01g/m³ |
Fluidizing Air Pressure | 1-2bar |
Gun data
Power Frequency | About 10KHZ |
Output Voltage | 0-100KVDC |
Output Current | 150uA |
Gun Weight | About 555g |
Safety Standard | IP54 |
Powder Output | About 550g/min |
High Voltage Installation Mode | Inside |
Polarity | Negative |
Container Capacity | 70L |
Packaging & Shipping
Our Services
we can supply the best price and the best sevice .
Company Information
We have more than 20year experiences on powder coating.
We are a typical Chinese supplier and specialized in the research, development
and production of car spray booths, furniture spray booths,
industrial spray booth,automatic
paint line,powder coating booth,powder coating oven,
powder coating gun,powder coating machinepowder coating line.
We insist in offering superior quality
products and efficient service.
If you are interested in any of our products or would like to discuss a custom order,
please feel free to contact us. We are looking forward to forming successful
business relationships with new clients around the world in the near future.
FAQ
Application: used for the powder coating and line, plant
Shipping: can ship to any port by sea / air.
Payment methods: escrow, T/T, paypal
Packing: proper packing suitable for container loading
Services: we supply all equipments about the powder coating, such as booth, oven, reciprocator, gun, line, semi-line and plant.
