13*23*32mm Flange Linear Ball Bearing Linear Motion Bearing LMF13UU

Product Overview

Description

13*23*32mm Flange Linear Ball Bearing Linear Motion Bearing LMF13UU







• Brand Name: THK, SAMICK, ABBA, HIWIN


• Precision Rating: N/C, H, P, UP, SP


• Model Number: LMF 100


• Place of Origin: China, Taiwan, Japan


• Material: Ball bearing steel, stainless steel


• Block: Flange


• Bore Size: 100 mm


• Outside Diameter: 150 mm


• Length: 175 mm


• Performance: Anti-friction, interchangeable


• Load Type: Heavy load


• Lubrication: Grease


• Weight: 900g

LMF100UU Flange Linear Bearing 100x150x175 mm Linear Motion Bearing







LMF100UU Flange Linear Bearing 100x150x175 mm Linear Motion Bearing





 Application for LMF100UU Flange Linear Bearing 100x150x175 mm Linear Motion Bearing

Description:
Linear bearing is a low-cost production of linear motion system, for unlimited travel in conjunction with the cylinder axis. As was carrying the ball point contact with the shaft, so use small loads. Linear bearing with minimal friction ball rotation, so that it can be smooth precision movement.


Application:

Auto, tractor, machine tool, electric machine, water pump, agricultural machinery and texile machinery ect.





Notes for buying LMF100UU Flange Linear Bearing 100x150x175 mm Linear Motion Bearing

• All items will be checked before packing. All items are new and of high quality.

• Please note that some countries will have custom duty or tax for certain items. It is the buyer's responsibility to pay all endued custom duty or tax. We are not responsible for any custom duty or tax since our price do not include this charge.
