big 86mm 2 phase 4 wired nema 34 stepper motor for cnc machine
- Category: Stepper Motor >>>
- Supplier: Changzhou,Jinsanshi,Mechatronics,Co.,Ltd.
Share on:
Product Overview
Description
86HS nema 34 series stepper moter :
| Model No | Step Angle (°) | Rated Current (A) | Phase Resistance (Ω) | Phase Inductance (mH) | Holding Torque (Kg.cm) | Motor Length (mm) | Leads No. | Motor Weight (Kg) |
| 86HS65-4004 | 1.8 | 4 | 0.7 | 3.9 | 32 | 68 | 4 | 1.7 |
| 86HS78-4204 | 1.8 | 4.2 | 0.45 | 4 | 45 | 78 | 4 | 2.3 |
| 86HS78-6008 | 1.8 | 6 | 0.5 | 4 | 45 | 78 | 8 | 2.3 |
| 86HS82-4504 | 1.8 | 4.5 | 0.32 | 2.8 | 45 | 82 | 4 | 2.5 |
| 86HS82-5608 | 1.8 | 5.6 | 0.35 | 3 | 50 | 82 | 8 | 2.5 |
| 86HS100-5004 | 1.8 | 5 | 0.5 | 4 | 68 | 100 | 4 | 3.2 |
| 86HS100-5008 | 1.8 | 5 | 0.5 | 4 | 65 | 100 | 8 | 3.2 |
| 86HS118-6004 | 1.8 | 6 | 0.6 | 6 | 85 | 118 | 4 | 3.7 |
| 86HS118-5608 | 1.8 | 5.6 | 0.6 | 6 | 85 | 118 | 8 | 3.7 |
| 86HS156-5504 | 1.8 | 5.5 | 0.7 | 9 | 120 | 156 | 4 | 5.5 |
| 86HS156-6204 | 1.8 | 6.2 | 0.75 | 9 | 122 | 156 | 4 | 5.5 |
| 86HS156-5608 | 1.8 | 5.6 | 0.65 | 9 | 120 | 156 | 8 | 5.5 |
Wiring Diagram And Dimensions:
Company Information
Our main products include stepper drivers for all stepper motor, stepper motor from size NEMA 8 to NEMA 42 series hybrid stepper motor, easy servo stepper motor and driver, and variable sizes linear stepper motor, stepper motor with gear box, stepper motor with brake. And we always research and develop new products.
