chinese CNC machine center VC1265(A)
High-rigidity/high-stability main structure
Use 3D-CAD and finite element analysis to delevlop high-rigidity machine tool structure
Resin bonded sand molding,twice aging,and special tank-type structure and optimized rib-reinforced lay-out,make the machine tool
of good rigidity and hysteresis loss
High-speed/high precision three axles feed structure
X.Y.Z three axles all adopt precise linear rolling guide rail(THK or HIWI) Less noise,low resistance,high speed,high precision Three axles all adopt C3 degree high precision ball screw,fix the poles of ball screw,fix the poles of ball screw and pre-pull,and optimize drive rigidity,reduce the heat distortion The poles of ball screw adopt the NSK high-precision angle of contact ball screw bearing
Use 3D-CAD and finite element analysis to delevlop high-rigidity machine tool structure
Resin bonded sand molding,twice aging,and special tank-type structure and optimized rib-reinforced lay-out,make the machine tool
of good rigidity and hysteresis loss
High-speed/high precision three axles feed structure
X.Y.Z three axles all adopt precise linear rolling guide rail(THK or HIWI) Less noise,low resistance,high speed,high precision Three axles all adopt C3 degree high precision ball screw,fix the poles of ball screw,fix the poles of ball screw and pre-pull,and optimize drive rigidity,reduce the heat distortion The poles of ball screw adopt the NSK high-precision angle of contact ball screw bearing
High-speed/high precision spindle
High rigidity,high precision,big hole diameter spindle design,adopyt the precise slide angle ball bearing support
High rotary spindle provides high-speed cutting for customers,ensure the long-term stabilization of machine tool's precision
The spindle adopts synchronous belt drive of big torsion,no friction and less noise
Fast-speed/reliable tool-change system
Can choose 20 bamboo split type or 24 arm press type ATC device,and can rotate the blade cutter very fast,steadily and reliably.
High rigidity,high precision,big hole diameter spindle design,adopyt the precise slide angle ball bearing support
High rotary spindle provides high-speed cutting for customers,ensure the long-term stabilization of machine tool's precision
The spindle adopts synchronous belt drive of big torsion,no friction and less noise
Fast-speed/reliable tool-change system
Can choose 20 bamboo split type or 24 arm press type ATC device,and can rotate the blade cutter very fast,steadily and reliably.
Specification
Name | VC1375A | Unit | ||
1 | Worktable | Size | 1500x650 | |
Loading | 1200 | |||
T-slot | 5-18*125 | |||
2 | Process range | X axis travel | 1300 | |
Y axis travel | 750 | |||
Z axis travel | 600 | |||
3 | Spindle | Taper model | BT50 | |
Speed | 60-6000 | |||
Driving type | belt | |||
Power | 11-15 | |||
4 | Feeding | X/Y/Z servo motor power | 4 | |
X/Y/Z servo motor torque | 22 | |||
Cutting feeding rate | 1-5000 | |||
X axis rapid movement | 18 | |||
Y axis rapid movement | 18 | |||
Z axis rapid movement | 15 | |||
