The New 1080P Mini Camera for Mobile DVR

Product Overview

Description

Model	JA-MC225
Image Sensor	SONY 1/3” IMX 225+2431H
TV System	PAL/NTSC
HD-Resolution	1.3 Mega pixel
Lens optional	f2.8mm
Effective Pixel Arrey	1280H x 960 V
Min illumination	Color 0.02 Lux F1.2 Black and white 0.0008 Lux
S/N Ratio	More than 60dB
WDR	D-WDR
IR	N/A
Infrared LED Range	N/A
horizontal angle of view	92°
Tilt Adjusting	Djustable
Power Supply	DC 12V±5%,65mA±5mA
Dimensions	49.5*47.5mm
Net Weight	400g
Weatherproof/Water Proof	N/A
Operational Temperature	-20℃~60℃
Operational humidity	<90%
vedio interface	Aircraft Round Connector Plug
