API 11E C serie Oil Well Pumping Unit Walking Beam Crank Balance Oilfield Equipment
Product Description
The API C series pumping unit is one kind of conventional beam pumping unit, which selects the crank balanced method.
Designed by modular and virtual manufacturing technology; optimized product structure; standardization, seriation, generalization.
Do finite element analysis to key structural component; high stability and reliability.
The reducer adopts balanced shunting evolvent or double circular arc to drive; well sealed, low noise, smooth operation, reliable and durable.
Simple operation, convenient maintenance and long service life.
Main Technical Param
API C Serie:
No.
Type
Polished Rod Capacity (Ib)
Stroke Length (in)
Rated Torque (in.Ibs)
1
C-228D-173-100
17,300
100,86,72
228,000
2
C-228D-173-74
17,300
74,64,54
228,000
3
C-160D-173-86
17,300
86,74,62
160,000
4
C-160D-173-74
17,300
74,64,54
160,000
5
C-160D-143-74
14,300
74,64,54
160,000
6
C-160D-173-764
17,300
64,54,44
160,000
7
C-114D-119-86
11,900
86,72,59
114,000
8
C-114D-143-74
14,300
74,62,51
114,000
9
C-114D-173-64
17,300
64,54,44
114,000
10
C-114D-143-64
14,300
64,52,40
114,000
11
C-114D-133-54
13,300
54,45,36
114,000
12
C-80D-119-64
11,900
64,53,42
80,000
13
C-80D-133-54
13,300
54,45,36
80,000
14
C-80D-119-54
11,900
54,45,36
80,000
15
C-80D-133-48
13,300
48,40,32
80,000
16
C-80D-109-48
10,900
48,37,25
80,000
17
C-57D-76-54
7,600
54,41,28
57,000
18
C-57D-109-48
10,900
48,37,25
57,000
19
C-57D-95-48
9,500
48,37,25
57,000
20
C-57D-89-42
8,900
42,33,23
57,000
21
C-57D-76-42
7,600
42,33,23
57,000
22
C-40D-76-48
7,600
48,37,27
40,000
23
C-40D-89-42
8,900
42,33,23
40,000
24
C-40D-76-42
7,600
42,33,23
40,000
25
C-40D-89-36
8,900
36,28,20
40,000
Packaging & Shipping
1. The body is naked in the container
2. Accessories are packed in iron case.
3. Flexible as order requires.
Company Information
Henan ZYZJ Pump Equipment Co.,Ltd is a professional enterprise of petroleum machinery manufacturing industry, specially in API series pumping unit, subsurface sucker rod pump, wellhead device, down hole tools, fittings and spare parts like polished rod and clamp, tubing pup joint &pony rod, crossover, centralizer, stuffing box and sinker bar ,etc of all common types in the industry.
Our company has passed ISO9001 quality management system and gained the membership of API. Our leading products are authorized with API 11AX, API 11E, API 5CT&5B, API 11B.And quite more patented products are developed.
