Life Raft with CE certification and Solas approved 8 person

Product Overview

Description



Life Raft with CE certification and Solas approved 8 person SOLAS approved throw overboard life raft with 8 person
Model No.	ATOB - 8
Shape	Regular hexagon
Capacity	8
Material	Neoprene coated fabric (buoyancy tube), water-proof cloth (canopy)
Cylinder	5L x 1
Gas composition	CO2 and N2
Lighting system	1 interior lighting lamp, 1 exterior indication lamp
Battery life	≥12hrs
Ballast system	4 x 60.5L water pockets
Temperature inflating range	-30 — +65°c
Max stowage height	18 - 50M from water surface
Use	Suitable for offshore cruising or open sea longer voyages ships
Standard	It meets the China MSA- "Regulations for the Statutory Surbeys of Ships and offshore Installations---Technical Regulations for the Statutory Surveys of Sea-going Ships Engaged in Domestic Voyages"2004, and its 2008 Amendments, Part4, Ch.3. and SOLAS(74/96) LSA, MSC.81(70), MSC.226(82), MSC.218(82), MSC.293(87),ISO15738(2002)
Equipment outfit	Solas A/ B pack
Life raft dimension (mm)	2390x2390x1250
Canister dimension (mm)	1090x615x530  (Solas A Pack)
	1042x554x486  (Solas B Pack)
Outer package dimension (mm)	1130x660x640  (Solas A Pack)
	1090x600x590  (Solas B Pack)
Weight (kg)	≤90
Conveyance:
Solas A Pack	Solas B pack
Qty/ 20'FCL: 54units	Qty/ 20'FCL: 67units
Qty/ 40'FCL: 112units	Qty/ 40'FCL: 138units
Qty/ 20'HQ: 141units	Qty/ 20'HQ: 174units
