HH 195 Digital Gold Silver automatic hot foil embossing hot foil stamping machine

Product Overview

Description

HH-195 Digital   Gold Silver automatic hot foil embossing hot foil stamping machine

OEM&ODM AVILABLE



Hot stamping foil machine paratemer:

Item Number	HH-195S	Max printing size	100x200mm
Worktable size	170x220mm	Stroker of stamping plate	38mm
Stamping temp range	Ambient-280 degree	Max work piece height	230mm
Stamping pressure	<130kgf	Max priting speed	1200pcs/hr
Power	220V 50Hz	Heating Power	900W
Max pressure	4-7 bar	Air Consumption	<58L/min
Dimensions	700x470x1550mm	Weight	Less 130KGs



Hot stamping foil machine features:

1. Microprocessor controlling, pneumatic units driving;

2. Stamping pressure, temperature and time adjustable;

3. Worktable could be adjustable for forth/back, left/right position,as well as turned slightly;

4. Auoto and adjustable paper feeding, collection;

5. According to different height of various substrates, stamping height adjustment through turning handwheel and stamping stroke adjustment by turning knob;

6. Available for bend and cylindrical substance printing, dismantle shuttle table for flat printing;



Hot stamping foil machine sample pictures:





About our company:

Dongguan Hengjin Printing Machinery Co. Ltd ( HENGJIN) is located in Guangdong Province,Dongguan City. From Guangzhou or Shenzhen about 1.5 hours. Hengjin has been a industry leading supplier of Pad printer, Screen printer, Hot Stamping Machine and the relative Accessaries supplies for 12 years under the same ownership. We have become well respected by our customers and others in the industry due to our knowlege of the pad print process and the personal attention we give to each and every customer. We offer a complete line of machinery and supplies of top quality and performance.



Hengjin as main an exporting Supplier in China. In order to give our customer more guarantee, avoiding more after-servucecaused. Only we using the spare parts to our machine good quality. The material of our machine is alloy cast aluminium and the surface is Powder spraying. The main parts which cylinder is from Original Germany FESTO.



Hengjin Printing machines which aboved mention have CE approval. And our customer from American, United Kindom, Germany, South American Etc. Sure Hengjin is a satisfying suppiler to you.
