Ozone Water Generator for Car Wash Gray Water

Product Overview

Description

Ozone Water Generator for Car Wash Gray Water



Product characteristics:

l ozone generating module which has steady performance is based on the medium of imported high purity ceramics, titanium alloy electrode and wind-cooling ventilation system;

l a standard reliable power module of high frequency and pressure makes ozone generating more efficient and steady and the unit lifetime will be longer;

l automatic power-off protection in case of overheat, overcurrent and backwater;

l output ozone concentration can reach up to 5% or more;

l it’s reliable performance enables this product to take the place of imported units;

l ozone output is adjustable from 0-100% according to different requirements;

l it is featured by small dimension, light weight, low maintenance and easy installation.



Technical parameters

- Ozone output: 5~500g/h

- Cooling type: built-in wind cooling

- Inlet dew point: -35°C

- Ambient temprature: -10~38°

- Output adjust: 0-100%

- Earth resistance: ≤4



- Ozone concentration: 60-80mg/L

- Ambient humidity: ≤80%

- Reaction chamber pressure: 0.05-0.1MPA

- Volts: 220-240V 50/60HZ

- Power consumption: 9KWh/kgo3

- Leaking concentration: ≤ 0.05mg/L





Technical Specification
Model	B3-90
Ozone output	90g/hr
Ozone concentration	60-80mg/L (8% by weight)
Feeding gas	Oxygen (has one built-in PSA oxygen generator)
Oxygen purity	90±3%
Cooling system	Air cooling (has two built-in fans)
Working pressure	0-0.01Mpa
Power supply	220V/50Hz
Power consumption	2500W
Operating temperature	-10-38 deg C
Relative humidity	Less than 85%
