Nitto Blue Tape No.3800A

Product Overview

Description

Nitto  Blue Tape No.3800A





Outline



Fixed Tape—using the polyester film as its base material. Due to this tape using the adhesive is less pollution to the adherend, it suitable to the temporary fixed electrical products and the components of the office machine. It is more convenient to use together with the fixed-length cutting knife with scale AS7.





Usage:



To use when transporting electrical products, office machinery and temporary fixed components.





Article Number	No.3800A	No.3800B
Thickness [mm]	0.07	0.08
Adhesive Force [N/25mm]	7.80	7.50	8.00
Overlapping Paste Adhesive Force [N/25mm]	0.10	4.32
Retentivity [mm/30Min]	0.2
Unreel Force[N/25mm]	0.69	2.45
Strength of Extension[N/25mm]	176.5	215.7
Ductility [%]	95	100
Base Material	Polyester





Note: The above data are only for the measurements of a case, is not a guarantee value.





Specification



Article Number	No.3800A	No.3800B
Base Material Thickness(mm)	0.038	0.05
50m Roll	-
200m Roll	-	-
Printing	-
Color	Light Blue	Light Blue, Saffron Yellow



For more product's and info, please kindly contact us.
