gasoline outboard motors 90HP for yachts(two stroke, T90BMX D,T90BML D,T90BEX D,T90BEL D,T90FEX T,T90FEL T)

Product Overview

Description

Item	Model	T90BMX-D	T90BML-D	T90BEX-D	T90BEL-D		T90FEX-T	T90FEL-T
Overall Iength	mm(in)	1337(52.6)		1337(52.6)			726(28.6)
Overall Width	mm(in)	398(15.7)		398(15.7)			374(14.7)
Overall height	mm(in)	1623(63.9)	1497(58.9)	1548(60.9)	1422(56.0)		1548(60.9)	1422(56.0)
Transom height	mm(in)	635(25.0)	508(20.0)	635(25.0)	635(25.0)		635(25.0)	508(20.0)
Weight	Kg	118	115	122	119		122	119
Full throttle operating range	r/min	4500-5500
Maximum output	Kw(HP)@r/min	66.2(90)@5000
Idling speed(neutral)	r/min	800±50
Engine type		Reed valve
Cylinders		L3
Displacement	Cm3	1141
Bore* stroke	mm(in)	82.0*72.0(3.23*2.83)
Ignition system		CDI
Control system		Tiller Control					Remote control
Starting system		Manual start		Electril/Manual Start
Gear positions		Forward-Neutral-Reverse
Gear ratio		2.0(26/13)
Trim and Tilt system		Hydraulic elevator				Electril tilt
Fuel tank capacitly	L	24
Maximum fuel waste	L/h	37
Mixing ratio	Fuel:Oil	50:1
Gear oil capacity	Cm3	610
Propeller options	In	3-13.25 x 17" (standard) or 3-13.6 x 13"
Propeller choice will vary by boat size and application
B=Back control, F=Front control, E=electric start, M=manual start, W=Electric start/Manual start S=short shaft, L=long shaft, X=Ultra long, D=Hydraulic elevator T= electric tilt







 PHELPS TWO STROKE 90HP OUTBOARD ENGINES FEATURES:
1. High grade marine aluminum alloy for ultimate corrosion protection
2. Tilt & trim with shallow water drive various positions
3. Twist grip throttle control for easy performance & safety
4. Thermostat controlled water cooling system
5. Safety lanyard with emergency shutoff
6. Easy forward-neutral-reverse gear shifting
7. Vibration reduction system for smooth performance
8. Start in gear protection for increased safety
9. Adjustable steering friction for easier maneuverability
10. CDI ignition system for trouble free starting
11. Innovative large recoil wheel assists easy starting
12. Quiet, through the propeller hub exhaust
13. Quality 24L fuel tank with hose
14. Include controls, basic instruments, fuel tube and tool kits

OPTIONS
1. Electric Start
2. Lighting coil and 12V DC output allow you to run a spotlight.
3. Remote Control with electric start
4. Power trim and tilt system or Hydraulic elevator
5. 13”, 17” different pitch propeller for different boat’s request

These outboards displacement is smaller, it easier for maintenance, will give you performance and reliability for your long days of boating. In many countries(especially for the developing areas) of the world where outboard demand is primarily for commercial uses, the water quality, weather and climate variance and long hours of continuous use make for a very harsh use environment.
This is the two stroke outboard motor series developed mainly for commercial use such as on fishing and passenger vessels. This series suits harsh conditions that include everyday use and situations involving long hours of continuous operation. Enhanced strength and durability in locations such as roller bearings, crankshaft and cylinder block, as well as an improved water pump that ensures plenty of cooling effect, combine to deliver substantial improvements in durability and reliability.
