Product Overview

Description



LPG-500 Beer Yeast Spray Dryer spray drying equipment

Equipment design condition
1, Liquid conditions
Liquid product name:                      beer yeast liquid
Initial moisture:                               ~85% (design as 80%)
Final Moisture:                                ≤5%

Water evaporation capacity            500kg/h

The liquid temperature:                   Ambient temperature
2, Processing conditions
Spray method:                                  Centrifugal atomizer
Liquid and the hot air contacting method: Co-current
Heat source and heating:               Electric heating
Inlet temperature:                         180~200℃(design as 180℃)
Exhaust temperature:                   90~100℃(design as 85℃)
Product Capture mode:                 Cyclone separator + wet scrubber

Product collect mode:                   Frozen dehumidification product collect

3, the design weather conditions  ( Standard )
Atmospheric pressure                     101.3KPa
Environment temperature:               10 ℃
Relative Humidity:                            80%
4, Public Works
4.1, Power
Power supply:                          380V, 3 phase, 50HZ
Power:                                     Drive 96.5kw + electric heating 1125kw

+ air sweeper electric heating 18kw
4.2, Compressed air
Pressure:                                 0.6 MPa
Consumption:                          1.5m³/min

4.3, Water

Pressure:                                 Cleaning water gun

Consumption:                           1000kg/h
4.3, equipment covers an area space       L × W × H    16m × 12m × 16m

Technical data sheet

Water Evaporation	500kg/h (pure water)	Diameter/Height	5.6M/13.5M
Operation temp	In 180℃-200℃ / Out 90-100℃	Atomizer LPG-500	Rolling speed 15500 rpm Diameter 150mm
Electricity Power	Drive 80kw
Heat supply	About 5.81 x105 kcal/h	Hot water consumption	1000kg/time (for cleaning)
Electric consumption	770-880 kilowatt-hour



Drying type	Open circle system	Feeding type	Screw pump
Hot air way	Co current	Heat source	Electric
Dust system	Cyclone separator + wet scrubber	Atomizer way	Centrifugal atomizer
