1.high temperature resistant, Borosilicate Glass Sheet And Pyrex Glass Sheet can work under 400°C continuously,and in short time can even work under 500°C,
2.Corrosion resistant, Except hydrofluoric acid, Oil Level Sight Glass do not react with any acid and base except hydrofluoric acid.the stability is
30 tims of the ceramic,and 150 times of stainless steel .
5.Electric insulation ,it is 10000 times of usual glass.
Compressive Strength
>1100Mpa
Coefficient of thermal expansion
5.5×10-7cm/cm.°C
Bending Strength
67Mpa
Hot work temperature
1750~2050°C
Tensile Strength
48.3Mpa
The temperature for a short time
1500°C
Poisson's Ratio
0.14~0.17
The temperature for a long time
1200°C
Elastic Modulus
71700Mpa
Resistivity
7×107Ω.cm
Shearing Modulus
31000Mpa
Dielectric Strength
250~400Kv/cm
Moths Hardness
5.3~6.5(Moths Scale)
Dielectric Constant
3.7~3.9
Deformation Point
1350°C
Dielectric absorption coefficient
<4×104
Specific Heat(20~350°C)
670J/kg °C
Dielectric loss coefficient
<1×104
Thermal Conductivity(20 °C )
1.4W/m °C
Typical Mechanical Property of Borosilicate Glass Sheet And Pyrex Glass Sheet
Production Flow
Application
Application :
Borosilicate Glass Sheet And Pyrex Glass Sheet is mainly used in electric light source, electrical appliances (electric), semiconductor, optical communications, military industry, metallurgy, building materials, chemical, machinery, electricity, environmental protection and other fields.
Packaging & Shipping
how to pack Borosilicate Glass Sheet And Pyrex Glass Sheet
1.plastic air cushion film
2.foam material
3.paper carton
4.wooden case
Shipping
Delivery Borosilicate Glass Sheet And Pyrex Glass Sheet within 1-7days after the payments by sea or by air,usually EMS,Fedex,DHL,UPS. and so on.
Our Services
1.sample :
We could like to give you suitable suggestion about Borosilicate Glass Sheet And Pyrex Glass Sheet to your detail application.
supply sample as required within 2-5days .
as the sample,we usually deliveried it by EMS,DHL,or SF-express.
So,customer can receive the sample within 4-10days .
2.OEM
accept OEM orders
3. after-salesservice
We promise that we can change or Refund the products if there are any quality problem.
Company Information
JinzhouHuameiQuartz Electrical Appliance Factory is one of the main professional
manufacturer of quartz products in China, was established in 2000 years, with experience
and history of 14 years.
we can supply quartz tube, Borosilicate Glass Sheet Optical , Quartz Crystal Plate ,quartz crucible,quartz instruments.
