3phase 380V 500A 15KGS feeder CE approved industrial heavy duty 3days delivery SMAW/GMAW/CO2 IGBT DC inverter welder MIG 500
- Category: MIG Welders >>>
- Supplier: Keyue Welding Equipment Co. Ltd.
Share on (60178121664):
Product Overview
Description
Product description
Product feature
- Support: MIG, TIG (Lift TIG) and MMA
- Wire: 1.0-1.6mm solid cored wire and flux-cored wire
- Protection: over-heat and over current.
- Material: Stainless steel, Carbon steel and so on
| Model | MIG-500 |
| Input voltage(V) | 3PH AC380V±15% |
| Input power(KVA) | 24.3 |
| Input current (A) | 37 |
| Rated output | 39V/500A |
| Output current(A) | 60-500 |
| No-load voltage (V) | 67±5 |
| Duty Cycle% (40℃ 10min) | 500A 60% |
| 387A 100% | |
| Efficiency (%) | 80 |
| Protection grade | IP21 |
| Insulation grade | F |
| Net weight (KG) | 36.2 |
| Gross weight (KG) | 40 |
| Dimension of WF package (mm) | 550*425*415 |
| Dimension of machine (mm) | 690*335*575 |
| Dimension of package (mm) | 740*400*630 |
Performance
Material | Sheet thickness (mm) | Stick diameter (mm) | Current range(A) | Model |
Carbon steel Stainless steel Low alloy steel
| ≥0.8 | 0.8/1.0 | 50-200 | MIG-200 |
≥0.8 | 0.8/1.0 | 50-250 | MIG-250 | |
≥0.8 | 1.0/1.2 | 60-350 | MIG-350 | |
≥0.8 | 1.0/1.2/1.6 | 60-500 | MIG-500 | |
Carbon steel Stainless steel Low alloy steel Aluminum
| ≥0.8 | 0.8/1.0 | 5-185A | MIG-200P |
≥0.8 | 2.5/3.2/4.0/5.0 | 25-350 | MIG-350H | |
≥0.8 | 5.0/6.0/8.0 | 25-500 | MIG-500H |
