CO2 Gas shielded flux-cored welding wire E71T-1
Product Description
1. Flux cored welding wire AWS A5.20 E71T-1 introduction:
E71T-1 is a kind of TI type flux cored wire for CO2 welding ,it has high cladding efficiency, good welding technical performance in all-position welding, apply for low carbon steel and 500MPA grade strength steel welding, such as ships, pressure vessels, mechanical equipments and bridges.
The wire for calcium oxide-type fluoride slag, CO2 gas shielded flux cored wire. Its excellent performance welding process, DC DCRP, arc stability, a small spatter, slag from easy, weld forming good for the peace of welding, Wang 400km welding and welding. Molten metal excellent mechanical properties, diffusible hydrogen content is low, high impact toughness, cracking good.
2. Application:
Metallurgical industry, Bridge building, Building industry, Chemical industry, shipping industry
Class: E71T-1
AWS: A5.20
Conforms to Certification: AWS A5.20 ASME SFA A5.20
Weld Process: Mig Welding Process
Specifications for Flux cored welding wire E71T-1
Mechanical Properties of Deposited Metal | ||||
Test Item | Rm(MPa) | ReL or Rp0.2(Mpa) | A(%) | KV2(J) |
Guarantee Value | ≥480 | ≥400 | ≥22 | ≥27(-20°C) |
General Result | 580 | 480 | 27 | 128 |
Chemical Composition of Deposited Metal (%)(CO2Shielding Gas) | |||||
Chemical Composition | C | Mn | Si | S | P |
Guarantee Value | ≤0.18 | ≤1.75 | ≤0.90 | ≤0.030 | ≤0.030 |
General Result | 0.05 | 1.46 | 0.42 | 0.01 | 0.017 |
Reference Current (DC+) | ||||
Wire Diameter(mm) |
| φ1.2 | φ1.4 | φ1.6 |
Current Range(A) | Downhand Welding | 120~300 | 150~400 | 180~450 |
Vertical Upward Welding and Overhead Position Welding | 120~260 | 150~270 | 180~280 | |
Vertical Downward Welding and Overhead Position Welding | 200~300 | 220~300 | 250~300 | |
Horizontal Welding | 120~280 | 150~320 | 180~350 | |
Packaging & Shipping
Packaging
1. 15kg/spool;
72 pieces/pallet
2. As clients’ requirement
Shipping:
1. Time: Normally ready goods within 8 to 25 days.
2. Term: CIF CNF/CFR FOB EXW
Our Services
- OEM is acceptable.
- Samples are provided for free.
Company Information
Lin’an Dayang Welding Material Co.,Ltd., located in the western part of Hangzhou, was established at the beginning of this century. It is a specialized company, which develops and produces all kinds of welding materials. We concentrite on profession, science and technology innovation, adopt advanced technology and equipment, to implement international quality standard.
