Technical Parameter:
Engine | |
Engine Type: | Single cylinder,air-cooled, four stroke, |
Displacement (ml): | 249 |
Bore X Stroke (mm): | 62.5x49.5 |
Compression Ratio: | 9.2:1 |
Max. Power (kw/r/min) | 11/7500 |
Max. Torque (N.m/r/min): | 15/6000 |
Max. Speed (Km/h): | ≥80 |
Lubrication: | Pressure ,splash |
Clutch Type: | Manual Clutch |
Ignition: | CDI |
Starting System: | Electric/Kick start |
Transmission System: | Chain drive |
CHASSIS | |
Front Brake: | Disk Brake |
Rear Brake: | Drum Brake |
Front Tire: | 90/100-21 |
Rear Tire: | 4.60-17 |
DIMENSIONS | |
L X W X H (mm): | 2120mmx 855mm x1190mm |
Seat Height (mm): | 1320 |
Wheelbase (mm): | 850 |
Min. Ground Clearance (mm): | 290 |
Max. Permissionable Weight : | 150 kg |
Rider Capacity: | 1 Person |
Battery | 12V/5Ah |
OTHERS | |
Packing Size (mm): | 1780*460*870mm |
Container Loading(40HQ): | 30pcs/20'GP, 62pcs/40'GP,96pcs/40'HQ CBU; 55pcs/20'GP,144pcs/40'HQ CKD |



Production Line

We have 2 different packing method of the motorcycle, one is SKD, the other is CKD. One container can load more CKD than SKD. After customer get the bikes, SKD is easy assemble, but need more freight. CKD can save more freight, but need worker to assemble completely.
1. CKD: wooden case
2.SKD: steel frame + carton or wooden frame + carton

We check our new cub motorcycle 100% one by one to make sure they are all what you ordered,
to make sure the quantity and in good condition.
1. We are professional motorcycle supplier in china .We have done motorcycle engine parts business more than 20 years.
2. All the motorcycles are high quality, best price you can find in China.
3. No matter this is a small order or a big one, we can insure send it to you in time.Moreover you can be our sole agent at your end, and get more commission when order amount is big.
4. We have our own brand: Pantera. You can use ours, but we can also make your Logo. We are a kind of professional team. We have matured quality control system.
If you are interested in our commodity, please feel free to contact us. We have sincere to have a good cooperation with you and then offer the best quality and service for you.
1, What’s the delivery time for production?
Honestly, it depends on the quantity and the season you place the order. It is about 20 to 30 working days. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
2, What’s your payment term of transaction?
We accept T/T, and if it is necessary, L/C is considerable. You can choose the one which is the most convenient or cost effective for you.
