pc based single channels Digital electrocardiograph EKG 1 Channel ECG Machine with printer
- Category: >>>
- Supplier: Nanjing Careland Medical Equipment Co. Ltd.
Share on (60184502447):
Product Overview
Description
Digital Single Channel ECG Machine CL-100
ECG-100E is a digital single channel electrocardiograph, which features in printing ECG waveform with thermal printing system, prompting for "Lead off" or "Lack of paper", multi-language interface, recording ECG waveform with manual or auto mode, convenient to operate.
1. High-resolution thermal printing array system.
2. Frequency response is as high as 150Hz.
3. Capable of printing continuously on channel trace and annotations including lead mark and parameter such as sensitivity, paper speed and filter operation status.
4. High resolution digital filter inhibits baseline drift without affecting ECG waveform.
5. One-touch operation.
6. Concept of floating input circuit meets IEC safety standard.
7. Rechargeable battery supporting more than 50 patient examinations.
8. Lead Standard: 12 leads.
Input Circuit | Floating; Protection against Defibrillator effect |
Lead | Standard 12 Leads, Lead change automatically |
Patient Current Leakage | <10μA |
Input Impedance | ≥10ΜΩ |
Calibrating Voltage | 1mV±3% |
A/D Conversion | 12 bit |
Frequency Response | 0.05Hz~150Hz (IEC) |
Time Constant | >3.2seconds |
CMRR | >80dB >100dB (with filter) |
EMG Filter | 35Hz (-3dB) / 25Hz (-3dB) |
Sensitivity | 1/2, 1, 2 (cm/mV), Conversion Deviation≤5% |
Recording System | Thermal-array 8 dots/mm ( vertical ) 16 dots/mm ( horizontal, 25mm/sec ) |
Paper Speed | 25, 50mm/s±3% |
Recording Paper | 50mm,20m, high-speed roll |
Input Circuit Current | ≤50nA |
Safety Standard | IEC class I, type CF |
Power Supply | AC: 220V / 110V, 50/60Hz DC: 12V rechargeable battery |
Skin Voltage Tolerance | ±300mV |
Noise Level | <15uVp-p |
Dimensions | 310mm×230mm×70mm |
Dimension of Packing | 400mm×280mm×160mm |
Weight | 2.75kg |
The equipment could be shipped by sea,air and express as per your needs.
The package will be delivered to your office effeciently and safely.
Standard Packing List :
1SET * ECG machine
1 SET* Patient Cable
1 Piece* Power Cable
1 piece*Power charger
1 roll* Printing Paper
1 set * Limb Electrodes
(4pcs/set)
1 set* Chest Electrodes
(6pcs/set)
1copy* Operation Manual
1 Piece* Power Cable
1 piece*Power charger
1 roll* Printing Paper
1 set * Limb Electrodes
(4pcs/set)
1 set* Chest Electrodes
(6pcs/set)
1copy* Operation Manual
----We Take Care You before & after sales!
Professional sales:
•We value every inquiry sent to us, ensure quick competitive offer.
•We assist you on every direct purchasing,project and bid tenders. Provide all necessary document.
•We are a sales team, with all technical support from engineer team.
Ontime delivery time:
•We put your order into our tight production schedule, ensure your punctual delivery time.
•Production / inspection report before your order packed
•Shipping notice/ insurance to you as soon as your order is shipped.
After sales service:
•We respect your feed back after receive the goods.
•We provide 12-24 months warranty after goods arrive.
•We promise all spare parts available in lifetime use.
•We care your complain within 24hours.
This equipment will be enjoyed 1 year warranty according to the international standard .We will responsible for repairing it or replace the related accessories free of charge if any malfunction happened for the equipment's own quality problem from the date of purchase.
For further information ,Please contact us ,we will be more than happy to fully assist with you in any project and tender.
