2021 woodworking cold press
- Category: >>>
- Supplier: Foshan Shunde Zhiyang Machinery Manufacture Co. Ltd.
Share on (60191677635):
Product Overview
Description
2021woodworking cold press
Product Description
The machine is applied for modern fashion board,plyboard,falke-board,laminating board,woodbased panel board,furniture manufacture,solid board furniture,speaker box,plastic and wooden mould etc.Easy to operate,working exact and fasthigh efficiency,It is the necessary pressed workpiece equipment in artificial panel,the composite furniture and solid board furniture manufacture material.
Model | MH3237X35 | MH3248X50 | MH3248X60 | MH324X25X2 | MH324X25X3 |
Worktable size(LXW) | 1000X2200mm | 1250X2500mm | 1250X2500mm | 1250X2500/2mm | 1250X2500/3mm |
Max pressure of worktable | 35t | 50t | 60t | 25tX2 | 25tX3 |
Pressing –plate max open distance | 1200mm | 1000mm | 1000mm | 1250mm | 1250mm |
Oil cylinder | Φ100MMx2PCS | Φ125MMx2PCS | Φ140MMx2PCS | Φ125MMx2PCS | Φ125MMx2PCS |
Hydraulic pump power/voltage frequency | 4KW(5.5HP)/380v50hz | 5.5KW(7.4HP)/380v50hz | 5.5KW(7.4HP)/380v50hz | 5.5KW(7.4HP)/380v50hz | 5.5KW(7.4HP)/380v50hz |
Weight of machine | 2000kg | 2450kg | 2800kg | 2900kg | 3200kg |
Overall dimensions(LXWXH) | 2580X1000X3330mm | 2930X1250X3130mm | 2930X1250X3130mm | 2930X1250X3130mm | 2930X1250X3330mm |
Details:
