Peristaltic Pump for HPLC
Peristaltic Pump for HPLC

Peristaltic Pump for HPLC

Share on (60193582241):


Price:$259.00

Quantity:


Product Overview

Description



Product Description


● Flow Rate: 0.000829-570mL/min
● Speed range: 0.5-150rpm
● Housing: Plastic coated metal housing compact structure
● Power consumption: ＜50W
● Drive dimension: 188*131*194mm
● Drive weight: 4.20kg


Technical Parameters


Flow rate
0.000829-570 mL/min
Speed range
0.5-150 rpm/min
Speed resolution
0-100 rpm, 0.1rpm; 100-600 rpm, 1 rpm
Testing time range
0.5sec-999sec
Outlet pressure
0.8-1.0 mm wall thickness tubing: 0.1 Mpa;
1.6-2.4mm wall thickness tubing: 0.1-0.27 Mpa
Display
LED Display
Control method
Mechanical keypad
Keypad lifetime
300,000 times
External speed control signal
0-5V, 0-10V, 4-20 mA for option
Start/stop, reversing signal
Passive switch signal, such as foot pedal switch;
Active switch signal: 5V, 12V and 24V for option
Communication interface
RS232, RS485 support MODBUS protocol(RTU mode)
Power supply
AC 220V±10% 50Hz/60Hz(Standard);
AC 110V±10% 50Hz/60Hz(Optional)
Drive dimension(LxWxH)
188x131x194mm
Drive weight
4.20kg
Power consumption
<50W
IP rate
IP31


Packing & Delivery


● Packing: 1 set/carton.
● Delivery Time: within 3 days after payment.
● Courier: DHL, TNT, UPS, Fedex, delivery door to door.
● Power Plug: GB, European standard, American standard, British standard.
