High quality new solventless lamination machine price

Product Overview

Description



ZWF300 Solventless Lamination Machine  Solventless laminating machine bag , pouch making machine



Quick Details
Condition: New
Place of Origin: Shanghai, China (Mainland)
Brand Name: Shanghai Zhou Tai
Model Number: ZWF300 Solventless Lamination Machine
Voltage: 3P,380V
Power(W): 50KW
Dimension(L*W*H): 5700*2600*2300MM
Weight: 8000KG
Certification: CE
Warranty: 12 months
After-sales Service Provided: Engineers available to service machinery overseas
Material: Film, Paper
Type: Solventless laminating machine
Automation: Yes,computer control
Strongpoint: Environmental protection

Specifications
ZWF 300 Solventless Laminator Machine
1st unwind dia.:600mm
2nd unwind dia.:600mm
Rewind dia.:800mm
Lam.speed:300m/min



Main technical:

1st unwind dia.	Φ600mm
2nd unwind dia.	Φ600mm
Rewind dia.	Φ800mm
Lam. speed	300m/min
Web width	800mm, 1050mm, 1250mm
Material	PET, BOPP, OPP, LDPE, LLDPE, PAPER



Feature

1.Take example of Spanish Comexi technique.

2.Unwind & Rewind is conic node type, for change material quick and convenient.

3.Metering roller, glue evenly roller and coating roller using imported servo motor (coating part)

4.Unwind & Rewind are AC motor

5.Glue evenly roller adopt automatic close structure when working, eliminate glue nonuniform (coating part)

6.Coating roll use high precise double layer propellers for glue and temperature uniformly (coating part)

7.Doctor dancer roller clean by motor driving, convenient cleaning and high efficiency

8.Taper tension and taper pressure for rewind, can increase yield

9.Pre-position for corona disposal, convenient add corona

10.Imported mixed glue device
12.Dance roller detection tension control for rewind and unwind











*  Specialized in bag in box, high speed;
*  Simple structure, operation convenient;
*  Extra-thick wallboard,  good stability;
*  Most important is bag in box will so popular in the future market.
