5 7 seats jeep 4x4 utility vehicle with diesel engine (CKD/SKD available for local assembling)

Product Overview

Description

5-7 seats jeep 4x4 utility vehicle with diesel engine:
- 5MT, Euro IV
- fuel saving (8L/100km)
- large passenger space
- fashionable design





5-7 seats jeep 4x4 utility vehicle with diesel engine (CKD/SKD available for local assembling):   2771cc diesel engine & 5 speed manual transmission;    made in year of 2015, with the newest 2015 version inner trim and dashboard, especially, the 4WD shift lever, now it has been only one shift lever, when you want to change it into 4WD, only press one button on the main shift lever you can easily change into 4 wheel drive steering;     fuel & engergy saving (only 8L diesel fuel consumption per 100km);     more economical and fashionable design;     with a larger and spacious inner room and space.





5-7 seats jeep 4x4 utility vehicle with diesel engine (CKD/SKD available for local assembling)





-- Techinical Datas of the 5-7 seats jeep 4x4 utility vehicle with diesel engine (CKD/SKD available for local assembling):



VEHICLE TYPE		6492D (4WD Diesel)
Body Parameter	Length x Width x Height(mm)	4885×1785×1920
	Wheelbase(mm)	3000
	Front Wheel-base	1475
	Rear Wheel-base	1485
	Gurb Mass(kg)	1808
	Gross Vehicle Weight(kg)	2460
	Seating capacity	7
	Tire Size	245/70R17
	Ground Clearance(mm)	215
	Oil tank capacity(L)	70
Power Parameter	Fuel	Diesel
	Engine	CA4D28C4-1
	Emission Standard	Euro IV
	Displacement(cc)	2771
	Fuel consumption(L/100km)	8
	Engine Type	Water-cooled, inline four-stroke,  turbocharged, common rail direct injection
	Maximum Power(Kw/rpm)	70±3 / 3600
	Maximum Torque(N.m/rpm)	225±5/(1600~2600)
	Compression ratio	17.2:1
	Max.vehicle speed(km/h)	120
Transmission	Transmission Type	5MT
Chassis Parameter	Approach Angle(°)	32
	Departure Angle(°)	24
	Brake Type	Front Disc Brake/ Rear Drum Brake
	Suspension(Front/Rear)	independent suspension /Leaf spring type non-independent suspension
	MinimumTurning Diameter (m)	13
	Drive Mode	4WD
	Steering Type	Recirculating ball steering gear





-- Standard Configurations of the 5-7 seats jeep 4x4 utility vehicle with diesel engine (CKD/SKD available for local assembling):



Exterior Equipment	Aluminum alloy step
	Alloy rim
	body color door handle
	Aluminum alloy luggage rack
	FASHION AIR DEFLECTOR
	Metallic Paint
Interior Equipment	new luxury inner triming
	adjustable steering wheel
	leather seat
	Third row folding small seat
	Front row three-point safety belt
	Second row three-point safety belt (middle seat two-point safety belt)
	Third row two-point safety belt
	Remote control central lock
	power window
	Environment heat and cold air-conditioner
	CD+MP3
	Loud Speaker
Safety	High rigidity vehicle body
	Front fog light
	SABS
	ABS+EBD
	high position brake lamp
	Interior anti-glare rear view mirror
	power rearview mirror







Detailed Pictures of this "5-7 seats jeep 4x4 utility vehicle with diesel engine (CKD/SKD available for local assembling)":







-- Complete 5-7 seats jeep 4x4 utility vehicle with diesel engine from different angles in orange color (front & rear):











-- other details of this 5-7 seats jeep 4x4 utility vehicle with diesel engine in orange color (including engine room, 2015 new driving cabin and dashboard, front & rear seats, inner trim, aluminium alloy wheel, etc.):























In this project, our Chinese company will provide technology support to your company, by sending engineers and technicians to your local place to training your staff, and passing on our China's knowledge your staff (including but not limited to the vehicle manufacturing skills, management system of the vehicle assembly factory, etc. ...); in the same time, supply the complete vehicle SKD/CKD parts for being re-assembled in your local place as well as the assembly equipments; and factory design, equipment layout in the factory, ... ...



1. What can we get from this vehicle assembly project?



1) Save customs duty, this is one of the most important factors, usually, in most of the countries, the customs duty rate for the KD parts (knocked down auto parts) is much less than the rate for the complete vehicle, the government wants to protect or develop their own industry, for example, in Nigeria, the tax rate on CBU (complete vehicle) is 35%, while only 5% for SKD, and zero percentage (0%) for CKD, this is a very good policy;

2) Save other taxes (tax exemption) in your country for importing such a vehicle in KD parts instead of complete built unit, for example, to exempt the VAT for 10 years, etc.;



3) Save shipping cost, for your information, usually, one 40feet container can load more units of the CBU 5-7 seats jeep 4x4 utility vehicle with diesel engine than the SKD/CKD 5-7 seats jeep 4x4 utility vehicle with diesel engine, calculated on average in large quantity, thus the cost is reduced down;

The above 3 points can be summarized as the following table in short, please check:



Comparison of the Vehicle Import (take Nigeria as an example, 7 seats Big SUV)
Status	tariff rate	loading units in a 40HQ	freight on per unit
CBU (complete built unit)	35%	2 units	half of the total cost for one 40HQ
SKD (semi-knocked down)	5-10%	2-2.5 units on average in quantity	half or less of the cost for one 40HQ
CKD (completely knocked down)	0%	2.5-3 units on average in quantity	one third or so of the cost for one 40HQ



Actually, the biggest advantage is: you can save a large percentage of import tariff; compared in the whole process, the shipping cost and the package is only small part. (the loading units of the KD parts vehicles will be according to the actual situation accordingly)

4) Earn your own Intangible Assets: with the vehicle assembly project, you can have, create and develop your own auto brand, logo and also exapand to the neighboring countries by using the preferencial tariff policy among your communities.

5) Creating more and more job opportunities for your local people of your country and driving and leading your country's industry to develop and stimulate the economic growth of your country, thus you can get more good and preferential policies from your government, this is a positive circle for the development of your assembly project, you win, the government win, the people win, all win !!!  Join us to put it into reality!!





2. What kind of partners we are looking for? or the conditions / requirements on the partner:



1) Investment Power Requirement: over 0.5-1 million USD for initial investment (for equipments);



2) Land or Workshop Requirement: over 15000-20000 square meters land including 5000 square meter workshop at least;



3) Software Requirements: Good Automobile Sales Channel, Familiar with Automobile Industry and Its Business, or Ralated business line;



4) Hardware Requirements on the Import Tariff: this is the most important factor, the difference gap between auto spare part CKD (completely knocked down) and CBU (complete built unit) shall be at least 30-35%, for example, import tariff on CBU is 35%, it must be 5% or zero on CKD.



5)  Good relationship with the local government, can get good / preferential policies from the government, or may odtain government orders for the assembly project and the plant.





3. What about the after-sales service?



We propose and provide "REPAIR & MAINTENANCE" after-sales service:



1) Found a professional bus "Repair & Maintenance" service company to ensure the After-Sales Service;



2) Spare parts supply;



3) Driving & repairing training guidance;

4) Technical advisory and training;

5) Market data feedback and disposing;

6) The most important - Technology Support.



To summarize, the above three (3) points are the reasons that why this vehicle assembly project can be successful in most of the countries, why we can succeed!!





Brief Introduction of our "China Big Group Company":



1. Our company is focusing on the vehicle assembly project throughout the world, so far, we have successfully set up several auto assembly plants in Syria, Ghana, Seychelles, Vanuatu, Angola, Nigeria for pickup, SUV, mini moke and mini bus assembling.



2. Our main products:



1) Truck/Pickup (Single & Double Cabin, Gasoline & Diesel Engine, 4x2 & 4x4 drive, LHD & RHD);



2) Big / Mini SUV (5 / 7 seats, Gasoline & Diesel Engine, 4x2 & 4x4 drive, LHD & RHD, Automatic & Manual Transmission);



3) Van (7-8 / 9-15 seats, Gasoline & Diesel Engine; 4x2 drive; LHD & RHD);



4) Car, Moke ( Gasoline & Electric, 4x2 drive, LHD & RHD, Automatic & Manual Transmission);



5) Bus (Mini Bus, Middle bus, City Bus, and Long-Distance Bus);



6) Providing complete set of assembly equipments of the above mentioned automobiles.







Here attached two of Our Company's overseas cooperation pictures for your reference:



-- Year 2009 in Syria (with our Syrian partners)







-- Our engineers working and teaching the local staff in our Ghana factory







If you are interested, contact us now, we will never make you disappointed ! Seize this opportnity, you win, we win, win-win !!

Looking forward to your cooperation!!
