Product Overview
Description
Refractory kaolin brick,Kaolin clay refractory brick,Kaolin fire brick
Features:
1. High refractoriness,High-temperature endurable .
2. Good corrosion resistance.
3. Good spalling resistance and wear resistance.
4. Good thermal shock resistance.
5. High mechanical strength.
6. High-temperature creep rate is low.
7. Good volume stability at high temperature.
Physical and chemical index:
Item/Grade | Fire clay brick | High alumina brick | ||||||
SK-30 | SK-32 | SK-34 | SK-35 | SK-36 | SK-37 | SK-38 | SK-40 | |
AL2O3 % (≥) | 30 | 35 | 38 | 45 | 55 | 65 | 70 | 82 |
Fe2O3 % (≤) | 2.5 | 2.5 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 |
Refractoriness(SK) | 30 | 32 | 34 | 35 | 36 | 37 | 38 | 40 |
Refractoriness under load, 0.2MPa, °C (≥) | 1250 | 1350 | 1370 | 1420 | 1450 | 1480 | 1530 | 1600 |
Apparent porosity (%) | 22-26 | 20-24 | 20-22 | 18-20 | 20-23 | 20-23 | 20-22 | 18-20 |
Bulk density (g/cm³) | 1.9-2.0 | 1.95-2.1 | 2.1-2.2 | 2.15-2.22 | 2.25-2.4 | 2.3-2.5 | 2.4-2.6 | 2.5-2.7 |
Cold crushing strength ,MPa (≥) | 20 | 25 | 30 | 40 | 45 | 50 | 60 | 70 |
Common sizes:
Straight type | Arch type | Wedge type |
L×W×H (mm) 230×114×65 230×114×75 230×114×32 220×110×60 220×110×50 220×110×40 220×110×30 | L×W×H/h (mm) 230×114×65/55 230×114×65/45 230×114×65/59 220×110×65/50 220×110×75/65 220×110×60/40 | L×W×H/h (mm) 230×114×65/55 230×114×65/45 220×110×75/65 220×110×60/40 |
Other sizes according to customer requiremen | ||
Application:
Fire clay brick is widely used in Blast furnaces, Hot Blast Stove, Steel ladle lining, Reheating furnace, Cement kiln, Tunnel kiln, Boiler, Coke oven, Waste incinerators ,Carbon furnace, Glass kiln , Steel smelting furnace and various kiln lining and thermotechnical equipment, etc.
