Dock construction and floating pontoon bridge rubber ship airbag
- Category: >>>
- Supplier: Qingdao,Xincheng,Rubber,Products,Co.,Ltd.
Share on:
Product Overview
Description
Dock construction and floating pontoon bridge rubber ship airbag
Specifications:
1.Reliable quality assurance
2.Reasonable price advantage
3.Factory direct sales
4.Timely after-sales service
Product Description
Name | rubber ship airbag |
Material | Natural rubber |
Characteristic | 1. High strength 2. Wear resistance and anti-aging 3. Good air tightness 4. Safety and reliability 5. High kneading & compressing resistance and damping capacity |
Applicable for ship | 1. Ship launching and ship landing airbags |
2. Rubber airbag for ship lifting,heavy lifting,caisson moving,upgrading,heavy building or constructions moving | |
3. Rescue and remove of wrecked ship. | |
4. High-pressure marine rubber airbags are used for ship launching, ship landing, ship lifting, hoisting, and floating. |
>------ Rubber ship airbags working shows:
>------ The display of marine rubber airbags:
>------ Rubber ship airbags technical specification:
* The available diameter of Xincheng airbag is from 0.8m-2.5m and effective length from 6.0m-20.0m.
* Other specification available upon customer’s request
* Besides,we can according to your ship information provide you the most suitable size, etc.
DIAMETER | WORKING PRESSURE | WORKING HIGHT | GUARANTEED BEARING CAPACITY PER UNIT LENGTH | ||
KN/m | T/M | Lb/ft | |||
D=1.2m (D=3.94FT) |
0.17Mpa (24.66psi) | 0.7m(2.296ft) | 133.61 | 13.62 | 9154 |
0.6m(1.968ft) | 160.30 | 16.34 | 10983 | ||
0.5m(1.640ft) | 187.08 | 19.07 | 12818 | ||
0.4m(1.312ft) | 213.76 | 21.79 | 14646 | ||
0.3m(0.984ft) | 240.44 | 24.51 | 16474 | ||
0.2m(0.656ft) | 267.22 | 27.24 | 18309 | ||
D=1.5m (D=4.92ft) |
0.13Mpa (18.85psi) | 0.9m(2.952ft) | 122.63 | 12.50 | 8402 |
0.8m(2.624ft) | 143.03 | 14.58 | 9800 | ||
0.7m(2.296ft) | 163.43 | 16.66 | 11198 | ||
0.6m(1.968ft) | 183.94 | 18.75 | 12602 | ||
0.5m(1.640ft) | 204.34 | 20.83 | 14000 | ||
0.4m(1.312ft) | 224.75 | 22.91 | 15398 | ||
0.3m(0.984ft) | 245.15 | 24.99 | 16797 | ||
D=1.8m (D=5.90ft) |
0.11Mpa (15.95psi) | 1.1m(3.608ft) | 120.96 | 12.33 | 8287 |
1.0m(3.280ft) | 138.22 | 14.09 | 9470 | ||
0.9m(2.952ft) | 155.59 | 15.86 | 10660 | ||
0.8m(2.624ft) | 172.85 | 17.62 | 11843 | ||
0.7m(2.296ft) | 190.22 | 19.39 | 13033 | ||
0.6m(1.968ft) | 207.48 | 21.15 | 14216 | ||
0.5m(1.640ft) | 224.75 | 22.91 | 15398 | ||
0.4m(1.312ft) | 242.01 | 24.67 | 16581 | ||
0.3m(0.984ft) | 259.38 | 26.44 | 17771 | ||
0.2m(o.656ft) | 276.64 | 28.20 | 18954 | ||
NOTE : THE ABOVE VALLUE IS FOR REFERENCE ONLY . IT IS SUBJECT TO CHANGE IN ACCORDANCE WITH ACTUAL AIRBAG SYSTEM DESIGN . YOU CAN CHOOSE THE REQUIRED OF SHIPS AND BOATS OF ALL SIZES. WE WILL MEET YOUR PROJECTS/SUPPLIED UPON CLIENTS REQUEST . | |||||
>------ Structure chart:
>------ The inflatable accessories of rubber ship airbag :
>------ Our equipments:
Company Information
Qingdao Xincheng Rubber Products Co., Ltd, which was founded in 1986, is a collection of
production,scientific research and design, product development, technical services for the
integration of enterprises, is the professional manufacturer of ship launching airbag, Pneumatic
rubber fender, marine rubber fender in China area. Company as the leading enterprise has
passed the certification of CCS , ISO9001:2008, SGS, BV etc.
TOP 10 ENTERPRISES OF RUBBER PRODUCTS IN CHINA
WELCOME TO VISIT OUR FACTORY!
Packaging & Shipping
PACKING : 1 .Packed in Woven bags or containter .
2 .It also depends on our clients' need .
DELIVERY : Usually 7 days, it depends on order's quantity.
PAYMENT TERM: 1. TT( 30% deposit, the balance money before shipment)
2. L/C at sight
FAQ
1. Design Service Life?
Will be more than 15 years if use as our advice.
2. Warranty Period?
It is 3 years.
3. Do u obtain CCS, ISO17357 and other certifications ?
Yes, We have get CCS, ABS, DNV, LR, BV, ISO17357 certification etc.
4. If can i get a good price?
We process the rubber sheet own instead of buy from the local supplier, which can reduce the cost and this profit will be give to the customers.
5. Why choose Xincheng?
"Quality first" is always our first principle.
We are looking forward to your inquiry and factory visitation is always welcome!
