Product Overview

Description

U71Mn 50kg Steel Rail Heavy Rail

Specifications

Heavy Rail:
Specification(KGS/M):38Kg, 43Kg, 50Kg
Standard: GB2585-2007
Material: U71Mn/45Mn/50Mn
Length: 12-12.5 meters/PCProduct Introduction

Heavy Rail:
Specification(KGS/M):50Kg
Standard: GB2585-2007
Material: U71Mn/45Mn /50Mn
Length: 12-12.5 meters/PC.





light rail 2





QGC_0602()




THE LIST OF YYGT

Name of Commodity Specificaton Materials Standard of Products Theory Weight Length of Dimension (m) Packed in bundle with iron wire (pcs/bundle)
Light Rail 4kg/m Q235 Q/YYG001-2008 4kg/m 6,8,9,10 75
8kg/m Q235 Q/YYG001-2008 8.42kg/m 55
12kg/m Q235 GB11264-89 12.2kg/m 36
15kg/m Q235/55Q/50Q GB11264-89 15.2kg/m 28
18kg/m Q235/55Q/50Q YB222-63 18.02kg/m 21
22kg/m Q235/55Q/50Q GB11264-89 22.3kg/m 21
24kg/m Q235/55Q/50Q Q/YYG001-2008 24.46kg/m 21
30kg/m Q235/55Q/50Q GB11264-89 30.1kg/m 15
Heavy Rail 38kg/m U71Mn/U71/45Mn GB2585-2007 Q/YYG002-2008 38.733 12,12.5 10
43kg/m U71Mn/U71/45Mn GB2585-2007 Q/YYG002-2008 44.653 10
50kg/m U71Mn/U71/45Mn GB2585-2007 Q/YYG002-2008 51.514 10
Crane Rail QU70 U71Mn YB/T5055-93 52.8kg/m 12,12.5 10
QU80 YB/T5055-93 63.69kg/m 10
QU100 YB/T5055-93 88.96kg/m 5
QU120 YB/T5055-93 118.1kg/m 5
I-beam of Mine Usage Steel 9# 20MnK/ Q235 YB/T5047-2000 17.69kg/m 8,9,10 28
11# YB/T5047-2000 26.05kg/m 18
12# YB/T5047-2000 31.18kg/m 15
U-beam Of The Mine Channel Steel 25U 20MnK/ Q235 GB4697-1991 Q/YYG006-2008 24.95kg/m 8,9,10,12 15
29U GB4697-1991 29kg/m 15
36U Q/YYG006-2008 35.87kg/m 15

Name of Commodity Specificaton Materials Standard of Products Theory Weight (kgs/set) Length of Dimension (cm) Packed in bundle with iron wire (set)
Fish Plate 8kg Q235B GB11265-89 0.8 +0.8 =1.6   50
1+1=2
12kg GB11265-89 1.1+1.1=2.2 45.5 50
2.6-3.0
15-18kg GB11265-89 3.6-4.0 53.54 25
4.6-5.0
5.6-6.0
22-24kg GB11265-89 6.6-7.0 61.73 20
7.6-8.0
8.4-9.0
30kg GB11265-89 14.4-15.0 71.48 10
16.4-17.0
43kg GB185-63 57.0-58.0 79 1

50kg
