3kw Dust collector for CNC Router

Type

EMF9030

EMF9040

EMF9055

EMF9075

Motor Power

3kw

4kw

5.5kw

7.5kw

Air volume

3150 m3/n

4450 m3/n

6000 -7000m3/n

8500 m3/n

Air speed

35-40m/sec

35-40m/sec

40-45m/sec

40-45m/sec

Inlet size

4’’x3pcs

4’’x4pcs

4’’x6pcs

4’’x6pcs

Collector bag

470x4pcs

630x4pcs

630x4pcs

796x4pcs

Dimension

1380x550x2000mm

1090x640x2200mm

1690x640x2200mm

2260x860x4000mm

Packing size

1300x560x520mm

1700x650x680mm

1700x650x680mm

2260x860x860mm

N.W./G.W.

67kg/70kg

95kg/104kg

120kg/127kg

166kg/170kg
