Product Overview
Description
PT-50T 1008,as the next innovativedigital multiplexer, that can provide more flexibility and reliability to fit for
differentnetwork and market demands. It combines traditional PCM feature, digital cross connection, fiber multiplexing or the Voice over IP technology all together seamlessly, just a simple click on the management program as customer wish.
The PT-50T 1008supports 3 types of networking mode: Optical uplink, E1 uplink or IP uplink are user definable. Total 4 x E1
portsare provided and by default as downlink in transparent connection mode. By management software, those ports can be defined as individual uplink just a point click, such capability increase the system flexibility tremendously as networking equipment with point to multipoint application.
PT-50T 1008 also provides 4 x 10/100Mb Ethernet switching ports, supports learning bridge and IEEE 802.1q port based VLAN. The Ethernet switching port supports Nx64K configure when make connection to the uplink port. Various type of voice and data interface cards are support for different applications, all voice and data interface cards are equipped with second level surge protector for enhancement of the reliability.
differentnetwork and market demands. It combines traditional PCM feature, digital cross connection, fiber multiplexing or the Voice over IP technology all together seamlessly, just a simple click on the management program as customer wish.
The PT-50T 1008supports 3 types of networking mode: Optical uplink, E1 uplink or IP uplink are user definable. Total 4 x E1
portsare provided and by default as downlink in transparent connection mode. By management software, those ports can be defined as individual uplink just a point click, such capability increase the system flexibility tremendously as networking equipment with point to multipoint application.
PT-50T 1008 also provides 4 x 10/100Mb Ethernet switching ports, supports learning bridge and IEEE 802.1q port based VLAN. The Ethernet switching port supports Nx64K configure when make connection to the uplink port. Various type of voice and data interface cards are support for different applications, all voice and data interface cards are equipped with second level surge protector for enhancement of the reliability.
* 3 uplink modes are configurable for different networking demand;
* Multi-services with voice / data, E1 and IP over optical link;
* Guaranty 100Mbps bandwidth for Ethernet transport over the fiber uplink;
* Provides 4 x E1 and 4 x 10/100BT Ethernet switching ports;
* Supports 30 x data/voice channels with additional 2 spare voice/data ports;
* RS232data module is orderable;
* Voice modules include FXS, FXO, Hotline,4WE&M, Magnet and Carrier;
* Second level surge protector are equipped on voice and data cards;
* Hot swappable 1+1 optic link protection;
* Support E3 and E6 line quality alarm on fiber link;
* 048Mb/s interface adopts high accuracy digital PLL circuit for clock recover;
* In-band management channel for remote control and system management;
* PTNMS supports configure backup, firmware / software onsite upgrade;
* Audible and visible alarm indication for local or remote unit;
* Alarm relay is provided for external alarm facility connection;
* The power supply can be AC220V or DC-48V or AC220V + DC-48V.
* Multi-services with voice / data, E1 and IP over optical link;
* Guaranty 100Mbps bandwidth for Ethernet transport over the fiber uplink;
* Provides 4 x E1 and 4 x 10/100BT Ethernet switching ports;
* Supports 30 x data/voice channels with additional 2 spare voice/data ports;
* RS232data module is orderable;
* Voice modules include FXS, FXO, Hotline,4WE&M, Magnet and Carrier;
* Second level surge protector are equipped on voice and data cards;
* Hot swappable 1+1 optic link protection;
* Support E3 and E6 line quality alarm on fiber link;
* 048Mb/s interface adopts high accuracy digital PLL circuit for clock recover;
* In-band management channel for remote control and system management;
* PTNMS supports configure backup, firmware / software onsite upgrade;
* Audible and visible alarm indication for local or remote unit;
* Alarm relay is provided for external alarm facility connection;
* The power supply can be AC220V or DC-48V or AC220V + DC-48V.
E1 Interface | ||||||||
Bit rate | 2048Kbps ±50ppm | |||||||
Code type | HDB3 code, G.703 standard | |||||||
Input impedance | 75W (default), 120Ω (optional) | |||||||
Frame structure | G.704, G.706 | |||||||
Compression law | G.711 | |||||||
Level | ±2.37V ±10% | |||||||
Optical interface | ||||||||
Bit rate | 150Mbps ± 50ppm | |||||||
Output optical power | ≥-15dBm | |||||||
Receiving sensitivity | ≤-35dBm | |||||||
Optical wavelength | 1310nm/1550nm | |||||||
Optical interface connecter | SFP/LC | |||||||
ETH interface (10/100M) | ||||||||
Interface rate | 10/100Mbps, auto | |||||||
Standard | IEEE 802.3, IEEE 802.1Q (VLAN) | |||||||
Connector | RJ45 | |||||||
Mechanical Dimension | ||||||||
Dimension | 440mm (W) x 250 mm (D) x 44mm (H) | |||||||
Net weight | 3.3Kg | |||||||
Power Supply | ||||||||
Input voltage | -48Vdc and/or 220Vac | |||||||
Voltage range | -36Vdc ~ -74Vdc, 165Vac~265Vac | |||||||
Power consumption | <10W | |||||||
Operation Environment | ||||||||
Working temperature | -10°C ~ 50°C | |||||||
Working humidity | <=90 % ( non condensed ) | |||||||
