Ningbo Haijiang plastic cup injection molding machine
- Category: >>>
- Supplier: Ningbo Haijiang Machinery Manufacturing Co. Ltd.
Share on (60204635573):
Product Overview
Description
Ningbo Haijiang plastic cup injection molding machine
Company profile prod
We supply all kinds of injection molding machines from 25T to 3000T, including color chips making machines, energy saving injection molding machines, gears making machines, dual clear color injection molding machine bakelite injection molding machines, PET preform injection molding machines, Fixed pump and variable pump injection molding machines,PVC fitting injection molding machines and etc.
Packaging & Delivery
Packaging Detail: Nude packing for PET injection molding machine price It need 1*20GP container for shipping delivery
Delivery Detail: 30 Working days PET injection molding machine price
Specification For Molding Injection
| |||||
Name of item | UNIT | A | B | C | D |
Theoretical shot volume | Cm3 | 2544 | 2835 | 3140 | 3461 |
Actual shot volume | g | 2315 | 2580 | 2858 | 3149 |
Oz | 65.4 | 82.7 | 102.1 | 123.6 | |
Screw Diameter | Mm | 90 | 95 | 100 | 105 |
Injection pressure | Mpa | 184 | 165 | 149 | 135 |
Injection rate | g/s | 552 | 612 | 679 | 748 |
Screw Stepless | r/min | 150 | |||
Clamping Force | KN | 6500 | |||
Opening Stroke | Mm | 870 | |||
Space Between tie Bars | mm×mm | 870*870 | |||
Mould Thickness | mm | 350-900 | |||
Ejector Stroke | Mm | 250 | |||
Ejector Force | KN | 150 | |||
System pressure | Mpa | 16 | |||
Pump motor | KW | 30+37 | |||
Heating capacity | kw | 42.95 | |||
Machine size(LXWXH) | m×m×m | 10.2×2.24×2.71 | |||
Machine weight | Ton | 28 | |||
