(ZCT CX05 RC01) Hot Selling With LED Display and Buzzer Cheap Digital Electrical Clinomete for Emergency Communication Car
- Category: >>>
- Supplier: Shanghai Zhichuan Electronic Tech Co. Ltd.
Share on (60209335465):
Product Overview
Description
China Shanghai ZC Sensor Hot Selling With LED Display and Buzzer Cheap Digital Electrical Clinometer in Emergency Communication Car
What is Features of our Cheap Digital Electrical Clinometer in Emergency Communication Car ?
Entirely industrial device;
Stable and reliable performance;
Automatically log function;
Wide power supply and power reversion protection
What is Specifications of our Cheap Digital Electrical Clinometer in Emergency Communication Car ?
Parameter | Test condition | Min. | Typ. | Max. | Unit |
Power supply |
| 8 | 24 | 36 | V(DC) |
Quiescent current(1 | No load VCC=24V |
| 60 | 100 | mA |
Alarm current | VCC=24V |
| 150 | 200 | mA |
Alarm angle | Relay action point | 2.0 | 7 | 9.9 | ° |
Relay contact capacity | 24V(DC)/250V(AC) NO |
|
| 10 | A |
24V(DC)/ 250V(AC) NC |
|
| 5 | A | |
Work temp range | display | -20 |
| +70 | °C |
sensor | -40 |
| +85 | °C | |
Measuring range | 1-axis | -20 |
| +20 | ° |
Resolution |
|
| 0.1 |
| ° |
Accuracy (2 | RMS |
|
| ±0.2 | ° |
Zero temp drift |
|
| ±0.05 | ±0.08 | °/°C |
Size | Display |
| 160*105*32 |
| mm |
sensor |
| 41*41*51 |
| mm | |
IP | Display |
| IP54 |
|
|
sensor |
| IP67 |
|
What is Packing Information of our Cheap Digital Electrical Clinometer in Emergency Communication Car ?
Product Photos
Our Certifications
Company View
What is Our Advantages?
1.Rapid response on any inquiry.
2.Competitive price.
3.Professional inspection department to guarantee quality.
