KEFEI brand LQ300 PET PVC PET PP recycle plastic prilling machine grantry type

Share on (60217889370):


Price:

Quantity:


Product Overview

Description


  KEFEI brand gantry type PVC PP PET ABS PPS recycle plastic granulating equipment

Product Description

 We customize the pelletizing machine for various kinds of particular materials, such as thermoplastic elastomer, high filling material, glass fiber composite material etc.

AS for the advanced requirements for plastic cutting machine from customers, we now have already manufactured the machine with easy cleaning and high torque with same structure and function from Germany plastic cutting machine(which is LIDA or AOMAI).

The main consumables, such as cutting knives, rubber roller etc are versatile to the original machine from German, and even more, we have made some improvement to this plastic pelletizer machine according to operation experience from users, which make the machine more convenient for operation

Packaging & Shipping

 Fumigation free plywooden pallet, seaworthy package

Our Services

24 hours on line service.

Chatting about the production process, package in workshop on Skype, Wechat, Trademanager with live video show can be supported.

We also provide plastic pelletizing machine maintaining service, cutting tool grinding, change rubber roller, traction roll and bakelite gear etc.

Company Information

 We are the special plastic pellet cutting machine manufacturer, was authenticated by Alibaba company, enjoying more than 10 years of honesty, cooperating with thousands of customers all the time, ensuring zero risk for your order, and the long term after-sale service for the plastic palletizing machine you buy from our company.

FAQ



1,Using tungsten-carbide alloy from special alloy factory, ensuring the enduring time of cutting knife.

 2,Adopting wear resistant and high temperature resistant modified rubber, is nearly more than two times the service cycle of normal rubber roller.

3.,All plastic pelletizing machine applies the imported bearings to make sure the stability, precision and low voice.

4,

3mm thickness of ss304 plate would be applied for panel of normal model, the bottom and feeding inlet which would easily erode is made of aluminium alloy.

5,The contacting part with raw material inside the cutting bin is completely made of ss304, also for cutting blade.

6,The cutting machine is all made of ss304, including cutting blade and panel.

7,Referring to the Germany cutting machine, the body of machine is much bigger, the stability and heat dispersion is much better, and there is quake proof rubber blanket installed under the cutting bin, the noise is reduced largely



Model

Motor power (kw)

Speed change

Strip cutting no.



Max. traction speed (m/min)

Granule size(mm)

Max. production capacity (kg/h)

Dia. X L of

Rotating blade (mm)

Blade number

Dia. X L of Rubber roll

(mm)

Dimension

LxWxH (mm)

LQ-25

0.75

Electromagnetic slip or VFD

<=3

72

Φ3x3

<=40

Φ90x50

14

Φ60x50

550x500x1200

LQ-6

1.1/1.5/2/2



<=8

72

Φ3x3

<=60

Φ120x96

14

Φ90x70

600x500x1300

LQ-300

Gantry

3~4



<=18

96

Φ3x3

<=300

Φ160x150

24

Φ100x150

950x850x1600

LQ-300

Cantilever

3~4



<=14

96

Φ3x3

<=300

Φ200x100

32

Φ120x100

1270x750x1510

LQ-500

Gantry

5.5~7.5



<=30

96

Φ3x3

<=600

Φ200x200

32

Φ100x200

1000x950x1700

LQ-500

Cantilever

5.5~7.5



<=30

96

Φ3x3

<=500

Φ200x200

32

Φ120x200

1380x800x1700
