non asbestos gasket material green sheet

Share on (60220527110):


Price:

Quantity:


Product Overview

Description



Product Description


   Cangzhou Shangdu Sealing Material Co., Ltd.


  Cangzhou Shangdu Sealing Materials Co.,Ltd is a professional manufacture of non-asbestos rubber sheet,industrial rubber sheet, sealed gasket materials and heat preservation materials.


                                                                 Non asbestos sheet NY150~550


                                          Non asbestos rubber sheet XB150~XB550


                                          Non asbestos gasket sheet JXB150~JXB550 with wire inserted


                                         CAF jointing gasket sheet with graphite


 Have experience in exporting to Pakistan,UAE,Iran, Vietnam, Russia,Ukraine etc.
















Product Description


                            Non asbestos rubber sheet



































































Asbestos Rubber Sheet Physical Property
GB/T3985-2008
ItemXB100XB150XB200XB250XB300XB350XB400XB450XB510
Thickness0.4  mm - 6.0  mm
Density 1.6  g / cm3  -  2.0  g / cm3
Burning Loss≤30%30%28%
Rebound degree354045
Temperature ℃100-110140-150200-220240-250290-300340-350390-400440-450500-550
Pressure   MPa1-1.51.5-22-33-44-57-88-911-1214-15







Size :   4120 mm x 1520mm,      2060 mm x 1520 mm,


              1520 mm x 1350 mm, 3810 mm x 1270 mm,


               1270 mm x 1270 mm, 1520 mm x 1520 mm,


                 1520 mm x 1020 mm or as request





Color:   Black, green, red, yellow, etc








Usage:   for the use of sealed gasket material in the flange connection of mediums, such as: water,





saturation steam, coal gas, etc.






















Packaging & Shipping


 Non asbestos rubber sheet packing


For 0.4mm-3.0mm in rolls with kraft paper inside and weave bags outside.


For 4.0mm-6.0mm with wooden pallets.


As customer's requirements, with wooden pallets.
