China 365nm Ultra violet Lamp High quality UV Lamp tube 8KW 700mm Light source for UV Curing LED machines

Product Overview

Description

Name: China 365nm Ultra violet Lamp High quality UV Lamp tube 8KW 700mm Light source for UV Curing LED machines







Products descriptions:



The HG lamp output UV spectrum is 350-450nm,the main peak is 365nm.











Application area:



Such as UV ink, UV glue, UV painting, UV coating etc.

Other industries like paper glazing, printing circuit board, decoration, wooden floor and flexible packaging, color printing, electrons, glassed, furniture and etc.

Various UV lamp is available in stock.









Products character:



1 High quality and stable performance.

2 The average lifetime is more than 800 hours.

3.Quick start with kr85 inside the tube.

4.Machine work instead of hands with high efficiency

5.Accept OEM order just give us your parameter below







Our Advantages:



1)Factory first hand price with over ten years experience producing lamps

2)UV lamps exported in global market ,such as USA/Russia/Brazil/Thiland/India.......





 UV Lamps data sheet :





Number	Power(w)	current(a)	Total Length(mm)	Arc Length(mm)	Diameter(mm)	Pipe Pressure(v)
1	250	5	115	45	within 25	120
2	500	4.5	145	45	within 25	140
3	1000	8.1	230	125	within 25	135
4	1000	8.1	335	190	within 25	135
5	2000	7.5	400	260	within 25	300
6	3000	5	620	460	within 25	700
7	3000	5	360	260	within 25	700
8	3200	12.2	360	260	within 25	290
9	4000	6.3	664	508	within 25	670
10	5000	7.5	775	625	within 25	750
11	5000	6.3	804	653	within 25	850
12	5600	7.2	826	673	within 25	950
13	6000	7.5	910	745	within 25	925
14	7500	8.8	803	653	within 25	950
15	8000	7.5	1150	1000	within 25	1200
16	8400	10.4	826	700	within 25	950
17	9600	6.6	1387	1247	within 25	1570
18	10400	5	1390	1270	within 25	2100
19	11000	6.3	1575	1419	within 25	1870
20	11200	7	1532	1400	within 25	2000
21	13000	7.5	1807	1651	within 25	1870
22	20000	10	1532	1400	within 25	2000
