Refractory brick,Furnace firebrick,SK30SK32SK34SK36SK38

Product Overview

Description

Refractory brick,Furnace firebrick,SK30SK32SK34SK36SK38

Characteristics:

1. High refractoriness.

2. Good spalling resistance and wear resistance.

3. Good corrosion resistance.

4. Good thermal shock resistance.

5. High mechanical strength.

6. High-temperature creep rate is low.

7. Good volume stability at high temperature.



Physical and chemical index:

Item/Grade	Index
	SK-32	SK-34	SK-36	SK-37	SK-38
AL2O3 %   (≥)	35	38	55	65	70
Fe2O3 %   (≤)	2.5	2.5	2.0	2.0	2.0
Refractoriness(SK)	32	34	36	37	38
Refractoriness under load, 0.2MPa, °C(≥)	1300	1360	1450	1480	1530
Apparent porosity (%)	20-24	20-22	20-23	20-23	20-22
Bulk density (g/cm³)	1.95-2.1	2.1-2.2	2.25-2.4	2.3-2.5	2.4-2.6
Cold crushing strength ,MPa (≥)	25	30	45	50	60
Thermal expansion at 1000°C (%)	0.6	0.6	0.3	0.3	0.2



Application:

Fire brick is widely used in metallurgy, petroleum, chemical industry, building materials, machinery processing, military, etc of thermal technology equipment.



Common sizes:

Straight type	Arch type	Wedge type
L×W×H (mm) 230×114×65 230×114×75 230×114×32 220×110×60 220×110×50 220×110×40 220×110×30	L×W×H/h (mm) 230×114×65/55 230×114×65/45 230×114×65/59 220×110×65/50 220×110×75/65 220×110×60/40	L×W×H/h (mm) 230×114×65/55 230×114×65/45 220×110×75/65 220×110×60/40
Other sizes according to customer requirements
