Price:$1.94

Quantity:


Product Overview

Description


5V 1A 5W ac/dc power adapter white



Product Description

 Specification:

ModelGLS-0501000GGLS-0502000GGLS-0503000G
AC InputVoltage100-240V AC 100-240V AC 100-240V AC
Input current0.25A/230V AC0.25A/230V AC0.25A/230V AC
Frequency47-63 Hz47-63 Hz47-63 Hz
Efficiency85% typical85% typical85% typical
Inrush current30A/230V AC30A/230V AC30A/230V AC
Leakage current<0.5A/240V AC<0.5A/240V AC<0.5A/240V AC
DC OutputVoltage5V5V5V
Current0-1000mA0-2000mA0-3000mA
Rated Power5W10W15W
Ripple&noise50mvp-p99mvp-p99mvp-p
Setup rise hold up time500ms,20ms,50ms/230VAC 500ms,20ms,15ms/115VAC at full load
ProtectionOver Load120%Max, hiccup mode auto recovery after fault condition is removed
Short CircuitAuto recovery
EnvironmentStore Temperature-20-85°C
Wokring Temperature0--50°C
Operating Humidity20%-80%RH
SaftyCECompliant to EN 60950-1:2006;   EN61000-6-3:2001;
EN 55022:2006+A1:2007;  EN61000-4-2/-3;
EN61000-6-1:2001; EN55024:1998+A1:2000+A2:2003
RoHsFree from lead, Cadmium, Mercury, Hexavalent
Chromium and/or PBB &PBDE
othersProduct dimension75*40*30mm
Weight0.13kg/pc
Packing100pcs/ctn,51*23.7*30cm
DC connector size5.5x2.1, 5.5x2.5. 3.5x1.35 or others
Cable length1.2M or others



Notes:

  1. Voltage and current can be adjusted by customer requirement.
  2. All parameters are specified at 230VAC input, rated load, 27°C 70%RH ambient.
  3. Ripple and noise are measured at 20MHz by using a 12 inch Twisted pair terminated with 0.1u and 47u capacitor.
  4. Tolerance: includes set up tolerance, line regulation, load regulation.
  5. DC voltage : the output voltage set at point measure by plug terminal &50% load.
  6. Line regulation is measured from low line to high line at rated load.
  7. Load regulation is measured from 20% to 100% rated load.
  8. The power supply is considered a component which will be installed into a final equipment .The final equipment must be re-confirmed that it stills meets EMC directives.



Product Pictures:

1-750.jpg 3-750.jpg 4-750.jpg

7-750.jpg B-750.jpg C-750.jpg

1.5A1-750

DC-750

Packaging & Shipping



Production process



Company Information






 Certificates:

 -750



Our Services
  •  Fast response to customer inquiries: reply within 10 hours.
  • Provide quality products: select good suppliers for raw material, inspec incoming components, monitor the production process, aging test every single unit before shipment.
  • Offer reasonable price
  • 2 years warranty
  • Offer competitive shipping price when required by customer
  • Provide customized products according to different requirement. OEM and ODM are available
  • Fast delivery after confirming the order.For the models we have stocks,we will ship them within 2 working days. For bulk order and customized models,please consult us for the shipping time.
