Product Overview
Description
Forklift Speed Alarm,ForkLift Truck Speed Limiter,Fork Lift Truck Speed Governor
Product Description
• Alarm can be controlled by remote controller within ten meters.
• Easy to operate with full functions.
• 4 levels volume adjustment for different occasions.
• External clear & loud alarm speaker, which up to 120dB.
• Two kinds of warning: Flash lamp and voice alarm.
• External super bright lamp flashing for speeding.
• Using WTV series voice IC as electro circuit core, easy to change different warning sound.
• Two level speed setting, level-1 with flash lamp warning, level- 2 with lamp and sound warnings.
• Alarm locking time can be adjusted from 0 to 99 seconds, if speed of forklift exceeds the preset, will warn.
• Eight-level waterproof capability, even work well in water.
• With connect and disconnect oil lines function.
• Consumption power: 5V
2.Technical parameters
• Working voltage: 12-24V (18-48V)
• Working power consumption: 5W.
• Warning lamp load≤100 mA/12V.
• Warning sound output: 120 dB.
3.The remote control function
The keys | Function | Operate description | |
| 1 | add | make the data on the function set up | |
| 2 | reduce | make the data on the funcation reduce down | |
| 3 | lock time setting | keep one second to enter setting.Once again is to exit the setting. | seconds |
| 4 | speed setting | keep one second to enter A,set level 1 speed warming light. Once again is to exit the setting. According to keep one second to enter B,set level 2 horn speed. Once again is to exit the setting.
| km/h |
| 5 | speeding record/volume setting | keep one second to enter setting.Once again is to exit the setting. | |
| 6 | ten meters set/unlock | keep one second to enter setting.once again is to exit the setting. |
Note: N2011A remote control keys are used for query speeding record function.
4.Applications
Lift truck, fork truck, forklift,small truck,scraper,dirty car
Agricultural Vehicle Speed Management
Industrial Vehicle Management
Transportations
