weighing scale pcb/bathroom scale pcb/bathroom scale load cell pcb
- Category: >>>
- Supplier: Shenzhen Htwy Technology Co. Ltd.
Share on (60227874308):
Product Overview
Description
weighing scale pcb/bathroom scale pcb/bathroom scale load cell pcb
Product Description
I. Who we are?
H.C.C. was established in 2004, an over 10 year PCB manufacturer in Shenzhen
We are 8 Year gold member at Alibaba
We are certified by ISO13485, TS16949, ULE332411, ISO14001, ISO9001
70% of our customers are from Europe and North America
We use very good material, such as KB, Shengyi, etc
100% of our prodcuts are tested and 100% pass before delivery
Fast samples for your test
Our customers including: SONY, DESAY, GREE, Gaoxinqi, Delta, etc
II. What we offer?
1. Prototyping
2. PCB manufacturing
3. Component sourcing and procurement
4. PCB Assembly
5. Hardware and software test
III. Quote requirement
1.Gerber file of the bare PCB board
2.BOM (Bill of material) for assembly
3. To short the lead time, please kindly advise us if there is any acceptable components substitution (for PCB assembly).
4. Testing Guide & Test Fixtures if necessary
5. Programming files & Programming tool if necessary
6. Schematic if necessary
IV. Our craft ability :
Specifications | Details |
Material Type | FR-4, CEM-1, CEM-3, Aluminium Clad,Arlon*,Teflon,Taconic, Rogers*, Polyimide*, Kapton,Dupont |
Material Thickness ( in inches) | 0.062”, 0.080”, 0.093”, 0.125”, 0.220”, 0.047”, 0.031”, 0.020”, 0.005" |
Layer count | 1 to 28 Layers |
Max. Board Size | 23.00” x 35.00”(580mm*900mm) |
IPC Class | Class II, Class III , Class 1 |
Annular Ring | 5 mil/side or Greater (Min. Design) |
Finish Plating | Solder(HASL), Lead Free Solder(HASL), ENIG (ELectroless Nickel Immersion Gold), OSP, Immersion Silver,Immersion Tin, Immersion Nickel, Hard Gold, Other |
Copper Weight | 0.5OZ-7OZ |
Trace/Space Width | 3 Mils or Greater |
Drill Clearance | 0.1mm(laser drilling) |
Plated Slots | 0.036 or Greater |
Smallest Hole (Finished) | 0.1mm or Greater |
Gold Fingers | 1 to 4 Edge (30 to 50 Micron Gold) |
SMD Pitch | 0.080” - 0.020” - 0.010” |
Soldermask Type | LPI Glossy, LPI-Matte, SR1000 |
Soldermask Color | Green, Red, Blue, Black, White, Yellow, |
Legend Color | White, Yellow, Black, Red, Blue |
CNC Route Point | Any |
Minimum Route Width | 0.031” |
Scoring | Straight Lines, Jump Scoring, Panel Edge to Edge, CNC* |
Body Gold | HARD*, IMMERSION* (up to 50 MICRON GOLD) |
Data File Format | Gerber 274x with embedder aperture |
Fab. Drawing Format | DXF, HPGL, DWG, PDF, Gerber |
E.T Testing | Flying Probe, Single Sided, 1up Plate, Clampshell, Net List |
Counter Sink / Counter Bore | Availiable up to 0.250 Diameter |
Control Impedence | Yes |
Blind Vias / Buried Vias | Yes |
Peelable Mask | Yes |
Carbon | Yes |
Packaging & Shipping
Packaging Detail: | Anti-static bag, bubble pack, carton box,Vacuum... |
Delivery Detail: | 3-15Days, delivery just-in-time |
