Heavy duty round duct making machine with plasma cutting
Heavy duty round duct making machine with plasma cutting is used for produce the round rigid air duct for ventilation purpose,maxinum flexibility.
Fetures of round duct making machine
- lock seam can be inner or outer lock for option.
- PLC control system with button operation
- Fast change steel duct mould system.
- Cutting systm can be plasma and roller shear for different thickness.
Main technical of round duct making machine
| 1 | Diameter | 80-1500mm |
| 2 | Thickness | 0.4-1.2mm |
| 3 | Strip width | 137mm |
| 4 | Strip feeding speed | 1-30m/min, adjustable |
| 5 | Suitable material | Galvanized steel, stainles steel |
| 6 | Main motor power | 11KW |
| 7 | Hydualic motor power | 4KW |
| 8 | Air compressor | 0.8MPa |
| 9 | Dimension | 2000 x 1800 x 1500mm |
| 10 | Weight | about 2900KG |
Packaging & Shipping
Packaging:
Stable wooden package protects machine from strike and damage.
Wound plastic film keeps machine out of damp and corrosion.
Fumigation-free package helps the smooth customs clearance.
The big size machine will be fixed in container without package.
Shipping:
For LCL, we cooperated with reputable logistics team to send machine to sea port speedily and safely.
For FCL, we get the container and do container loading by our skillful workers carefully.
For forwarders, we have professional and long-term cooperated forwarders who can handle the shipment smoothly. Also we would like to have seamless cooperation with your forwarder at your convenience.
