Product Overview

Description

SX-G-D device for efficient dust removal desulfurization is a collection of dust removal, desulfurization, dehydration (mist) in the integration of equipment, the flue gas into the upper shell of equipment, installed at the inlet channel atomized spray device, spray absorber after form even tiny droplets, the droplets with flue gas mixture, and flue gas temperature decrease to facilitate the absorption of SO2 in flue gas.Import flue for horizontal double tangential inlet structure, after the flue gas into the shell forming strong collisions, the flue gas after being atomized droplet humidification and cooling in the collision zone further adhesion in cohesion, form efficient hybrid washing purification process, the soot and SO2 in the flue gas is efficient washing.Through efficient washing flue gas into the shell of the three-phase separation tube, in the three-phase separation tube, the soot, grey water absorbent washing down reactants and after purification of the flue gas and SO2 was efficient separation.DTTW - type II device for efficient dust removal desulfurization with double alkaline desulfurization technology, the absorbent PH value, easy to control, can be mounted to the automatic control system.The equipment is suitable for a variety of desulfurizer, and can use CaO, CaCO3, NaOH, Na2CO3, slag waste water, alkaline waste liquid, etc., with the change of the desulfurizer, desulfurization efficiency in 75 to 90% of the device, various technical indicators are better than the relevant environmental protection standards.DTTW - II type device for efficient dust removal desulfurization has corrosion resistance, wear resistance, small volume, low operating cost, simple operation, easy to automatic control, flue gas flow resistance is small, induced draft fan without water, the system does not scale, washing liquid circulation use, high efficiency of dust removal desulfurization, etc.

Want to know more, contact me!



Specification	6	10	20	35	75
Airflow(m³/h)	18000-21000	30000-34000	48000-52000	84000-91000	180000-195000
Inlet wind speed (m/s)	11.9-15.8	17.4-21.6	20.6-24.4	17.8-20.7	16.6-18.9
outlet air velocity (m/s	8.7-11.5	13.0-16.6	16.5-19.5	13.0-15.3	14.7-16.6
collection efficiency (%)	95-99
desulfurization efficiency (%)	more than 95
Ringelman black	less than 1level
Resistance (pa)	less than 1200
Moisture percentage (kg/m³)	1.2-2.0
Adaptive weight of boiler (t/h)6	6	10	20	35	75

  Want to know more details to contact me!







SX/G - D series wet efficient desulfurization dust removal device is adopted pressure type threestage dust removal desulfurization and terminal dehydration principle, using water (alkali absorption liquid) as medium, the harmful material such as dust and SO2 gas in the flue gas with water (alkaline absorbing liquid) a good contact with step by step, forming an effective capture and absorption liquid fog layer, through the solid, liquid, gas mass transfer reaction, soot and SO2 from the flue gas to remove. Its working principle is dust, flue gas sulfur first through the flow channel, and the nozzle, alkaline liquid (such as lime) in fog water droplets, dust particles in flue gas after a fierce collision contact with atomized water, in the water flow under the action of impact, a large amount of alkali solution splash, form effective gas washing purification process, in the process of movement, the dust gas of SO2 with alkali reaction, neutralization into neutral substances, SO2 and dust is effectively capture, purge gas after dehydration unit to remove water mist, through the chimney into the atmosphere.









1, with double conical tower dust removal, the mud does not contact are compared.in addition, prevent the sticky ash caused by congestion.
2, sprinkler head is installed outside the area of dust, made with the method of nozzle shall not contact, solved due to the nozzle blockage of water gush out influence dust absorption effect.
3, using twin towers directly on the two chimneys of shaft kiln, walking detours to avoid the flue gas resistance, resistance is low, so equipment without using induction wind also won't produce the phenomenon of the anti-smoking.
4, with large water dust removal, spur circulating water, the water temperature is low, so can solve the pipeline structure, water vaporization, and dust removal effect is bad.
5, all use of circulating water, never to kiln emissions and waste water.
6, the back out of the dust collecting wastewater by mud separator will quickly separate, mud and water separation of mud to double shaft mixer with porridge paste straight line, and do not need any mud dedicated equipment, recovery of 100% recycled slurry, unique to the secondary pollution problem caused by the ground.

1. Equipment made of high quality carbon steel and high temperature resistance, wear resistance, corrosion resistant material; Using stainless acid-resistant steel spray device, the terminal is equipped with vortex dehydrator, good structural performance, heat resistance, abrasion resistance, corrosion resistance, high dehydration anti-aging performance, long service life.

2. Equipment cover an area of an area small, the use of simple operation, easy installation and maintenance, stable operation, low operation cost.

3. Equipment has the function of integration of sulfur removal liquid gas contact surface area is big, high sulfur removal efficiency (above 95%).

4. Can make full use of alkaline waste water or slag water industry, boiler sewage wastewater for sulfur removal absorbent, not only save energy, and no secondary pollution, conform to the requirements of the construction of "two type society" and environmental protection.

5. Equipment operation process is simple, high efficiency, installation simple and easy to operate, quick construction cycle, can meet the requirements of environmental protection construction as soon as possible.
