Hot Selling hose reel sprinkler irrigation high efficient energy saving hose reel sprinkling irrigation machine

Product Overview

Description

Products Name:  Water Gun irrigation equipment





Products Picture:



Model: XF1151-JP50

Model: XF1151-JP65/75/90

Model: XF1152 with Support Truss





Detailed Specification:



XF Series	Model	PE-Hose Dia.	PE-Hose Length	Max. Flexible Length	Flow Rates (m3/h)	Nozzle Dia. (mm)	Working Pressure(Bar)
HR50	50-150Tx	50	150m	2×180m	7--16	11--14	3.5 - 7.6
HR65	65-220Tx	65	220m	2×260m	13 - 32	14 - 22	3.5 - 10.0
	65-250Tx	65	250m	2×290m	13 - 32	14 - 22	3.5 - 10.0
	65-340TX	65	340m	2×380m	13 - 28	14 - 22	3.5 - 10.0
HR75	75-300TX	75	300m	2×345m	13 - 38	14 - 26	3.5 - 10.0
	75-350TX	75	350m	2×390m	13 - 38	14 - 22	3.5 - 10.0
	75-400TX	75	400m	2×435m	13 - 30	14 - 20	3.5 - 10.0
HR90	90-250TX	90	250m	2×300m	17 - 65	16 - 30	3.5 - 10.0
	90-300TX	90	300m	2×350m	17 - 65	16 - 30	3.5 - 10.0



Products Feature:



1. Mainly composed of frame, reel, water turbine,HDPE hose,gearbox and water carriage,tire and accessories.

2. Easy operation and installation with simple and compact structure,ok to operate by 1-2 persons.

3. PE Hose can be automaticly rewinded to save labor costs.

4. 360°sprinkling coverage to ensure the farm irrigation efficienct and uniform

5. Widely used for fruit and vegetable irrigation, farmland irrigation,power plantetc.

7. Water spray car can retrieve the tube fast even under the low flow conditions, up to 180m/h, help to adjust the sprinkler area according to the actual irrigation requirements.



 Working Picture:
