flexible pcb 8 Layer fpc Flexible Rigid PCB manufacture Flex PCB Cable (FPC) Rigid Flexible pcba assembly

Product Overview

Description

 flexible pcb 8 Layer fpc Flexible-Rigid PCB  manufacture Flex PCB Cable (FPC)  Rigid Flexible PCB lex pcba assembly



if have Gerber file or enquire. please email is violet(at)akesoncircuit(dot)com(dot) cn

Type	PCB	FPC
Scope	Multilayers(1-40layer),HDI(4-20)	Flex,Rigid Flex
Multilayers	1-40 layers, board thickness  8mil-126mil (0.2mm-3.2mm)	4-40 layers, board thickness 15mil-126mil (0.38mm-3.2mm)
HDI Buried/Blind Via	4-18 layers, board thickness 15mil-126mil(0.38mm-3.2mm) 1+N+1,2+N+2,3+N+3,Anylayer	4-20 layers, board thickness 10mil-126mil(0.25mm-3.2mm)
HDI	/	1+N+1,2+N+2,3+N+3,Anylayer
Flex & Rigid-Flex PCB	/	1-8layers Flex PCB ,2-12layers Rigid-flex PCB HDI+Rigid-flex PCB
Laminate	Shengyi,EMC,ITEQ,Panasionic,Hitachi....
Soldermask Type(LPI)	Taiyo,Goo’s,Probimer.....	Taiyo,Goo’s,Probimer FPC.....





Deliverables
1/Quotes in 24 hours or less
2/Standard production leadtime of 20 working days (4 weeks)
3/Prototype leadtime of 5 to 10 working days (1-2 weeks)
4/Stack-ups and impedance simulation in 36 hours
5/Initial response to technical questions or quality concerns in 36 hours
6/DFM and EQ's prior to PO placement upon request
Quality system
1/Akeson has mature and stringent Q
2/100% AOI, 100% ET, 100% FQC + FQA
3/SPC and Cpk programs
4/Lean Manufacturing and 6S programs
5/Advanced inspection and lab equipment
6/Standard QA report with every shipment
7/RoHS and REACH Compliance
8/Conflict Minerals Compliance
Products infomation
8 layer,
Material:FR4(Tg180) material,
PCB thickness:1.60mm thick,
Final copper:1 OZ finished copper on all layers,
Surface:ENIG surface finish,
Ttchnology:with hard gold finger at edge-board,
Solder mask:green solder mask,
with impedance control
6.0/7.0mil min w/s(line width/spacing),
min drill bit:0.20mm,
min BGA pad size:0.33mm
