(1) reactors are the main part of the pyrolysis system.
(2) light oil gas will be generated when the inner temperature reaches 100 °c, 250-280°c is the best temperature for the out put rate.
(3) inside it, there exists the insulation layer which is better at the heating insulating property.
(4) Auto welding, and radiographic testing.
(5) The above reactor is customized, some parts of the reactor could be manufactured according to you actual requirement,
such as the type of the feeding door, the installation, the shape, colours etc.
3. The secification of the reactor
Model
reactor size(mm)
weitht(Mt)
volume(m3)
space required(m²)
capacity(Mt/batch)
note
XD-5
2000*5000
27
22
80-100
5
3 batches /2 days
XD-6
2200*6000
30
23
100-120
6
3 batches /2 days
XD-8
2200*6600
32
25
150
8
1 batch per day
XD-10
2600*6600
38
35
150-200
10
1 batch per day
XD-12
2800*6600
40
40
150-200
12
1 batch per day
4. The details of the pyrolytic process
Reactor
1. Made by Q345R boiler plate. Also can choose SS310, 310S+Q345R
2. Auto-welding both inside and outside
3. With rock wool insulation board
Catalyst chamber
1. Improve oil yield and oil quality
2. Reduce the speed of oil gas so that it can be better cooled
Oil-water separator
1. Separate oil and water
2. Collect heavy oil
Condenser
1. The oil gas is cooled separately by small pipes inside condenser
2. Light oil is collected here
Vacuum device
Keep machine running under normal pressure
Anti-back fire device
1. Recycle residual gas to furnace as fuel
2. Water sealing design prevent tempering
Dust removal device
Dispose of flue gas caused by using coal, wood, oil or natural gas
Packaging & Shipping
The truck and the vessel is the transport machine, transportation by land or sea is avaliable.
The equipments is transported with the parts of the equipment (installation on your working place)
The whole equipment could be put into the container.(the size according to the capacity of the equipment)
