Industrial pallet washing machine/Plastic pallets washing machine

Product Overview

Description



China Joy Machinery and Equipment Ltd supply crate washer / tray washer which could handle most of the vast variety of sizes, shapes of plastic crate /boxes/trays/basket/plastic pallet/ plastic cage/barrel etc.

The tray washer is with capacities from 150-1800 crates/ hour depending on the degree of soilage.



The crate washer machine consist of 2-5 separate washing systems:

1. Hot alkaline water cleaning or hot water cleaning(0-120°C adjustable)

2. Hot water cleaning or cold water cleaning (0-120°C adjustable)

3. Cold water rinsing part

Each part is configured with separate water tank, water pump and double filter trays to prevent any blockage. The water could be re-circulated used with low water consumption.

The entire machine is built up in AISI 304



Options:

- Pre-rinse section

- Heating mode: Steam, hot water, gas and electric

- Overhead conveyor for “one man” operation

- Disinfection

- Automatic destacking, drying and stacking



Unique characteristics:

- Manual variable top and side guides for handling of multiple crate sizes

- Suitable for various industry and plastic boxes/crates/trays/baskets/bins etc

- Plug and play solution

- Easy to operate and maintain

- 24x360 days working time available

- Long service time

- Environmental friendly-low water and detergent consumption

- Cross nozzles to ensure that all surfaces are cleaned

- Stainless steel nozzles

- Double filter to prevent any blockage in the pump or nozzles



Model	Cleaning Units	Motor power	Water Pumps	Capacity	Machine size
JME4500	2	0.75kw	4kw*2PCS	200-300pcs/h	4000x1500x1700mm
JME5500	3	0.75kw	4kw*3PCS	400-800pcs/h	6000x1500x1700mm
JME8000	4	0.75kw	4kw*4pcs	800-1200pcs/h	8000x1500x1700mm
JME10000	5	1.5kw	5.5kw*2, 4kw*3PCS	1500-1800pcs/h	10000x1500x1700mm
Remark	Hot water heating device: Steam or 27kw electric heating device.







China Joy Machinery and Equipment Limited is a professional manufacturer of food processing machines and high pressure cleaning equipment.

We are a comprehensive enterprise which integrates research,development,manufacture,installation and

maintenance.We have advanced equipment,rich experience,highly-qualified scientific researchers and professional staff members for the after-sales service.

We specialized in designing and producing fruit and vegetable processing line which is including fruit and vegetable washing machine,drying machine,peeling machine,slicing machine,chopping machine,sorting machine,mixing machine,and potato chips production line,meat processing line and high pressure cleaning pump,hydro test pump etc.

Our products had been exported to more than 60 countries,all the products had been gained high praise from the customers at home and abroad.

We will continue to follow the policy of “quality first,reputation first,customer first”.And sincerely hope to cooperate with much more customers all over the world.
