CH 481 Hot sale 9kw ATC power spindle wood cnc router price

What is the Features of  this cnc router machine?

1.Body structure: Cast steel body with aging &tempering treatment, solid and durable.

2.Air cooling spindle: Imported ceramic bearing,with good thermail proteciton function,durable and powerful.

3.Driving system:Three-axis servo motor, high resolution and positioning accuracy.

4.Transmission device: High precision gear & pinion  for X and Y axis, Taiwan ball screw for Z axis.

5. Drag chain: special drag chain with function of anti interference,anti static, high flexibility.

6. Vacuum worktable: European design, ensure the adsorb strength to be equal.

7. Linear guide: adopt Taiwan linear slid rail, high accuracy, ensure heavy loading and long lifetime.

8.Software: TYPE3,CAXA,MASTERCAM,ARTCAM,UG etc.

What is the Parameters of cnc router this machine?

What is the main parts and their features or advantages?

NO.	Detail Pictures	Items	Brand
1		Vacuum Worktable	Divided into 4 area * 32holes/area. Equipped with 7.5kw water pump.
2		Spindle	9kw HSD Air-cooling Spindle(Italy)   With automatic lubrication, it don't need to add oil external; Strong torque, high efficcient processing speed, suitable for technological cutting, milling and other heavy processing technology, ensure edge neatly without a ripple.
3		Tool Change Device	8 tools automatic change knife library ( Moveable type)
4		Driving System	Yaskawa Servo Motor and Driver(Japan) With imported precision bearing, large torque, long working hours. Three axis drived by Japan Yaskawa Servo Driver, high resolution and positioning accuracy.
5		Transition	X,Y axis adopt oblique rack gear; Z axis adopt Taiwan AHK high precision preload anti-backlash ball screw, screw nut with tracking airtight dust removal device, guarantee the machine precision and service life.
6		Guide Rail	Y axis adopt Taiwan Hiwin 30mm guide rail; X axis and Z axis adopts Taiwan Hiwin 25mm guide rail, adding scraping devices external and dust proof protection, extending the service life of the guide rail effectively.
7		Frequency Inverter	Taiwan Delta Frequency Inverter (9kw)
8		Electrical Component Breaker	Germany Schnelderd
9		Electrical Component Cable	Germany Helukabel Special shielded cable drag chain special high flexible, can bend millions of times, drag chain support 150 degrees bend, effectively protect the cable
10		Reduction Box	Japan Simpo
11		Approaching Sensor Switch	Dust proof, waterproof & antiseptic (3 pcs for X,Y and Z axis)
12		Heat Dissipation	Fan Cooling
13		Control System	Taiwan Syntec System, visualization operation, real- time simulation, pretreatment ability
14		Software Available	Artcam, Alphacam, Mastercam, Type 3, UG, Caxa, JD Paint, etc.
15		Collet	8 pcs

Applications of   cnc wood working machine price cnc router

Woodworking Industry: Three-dimensional wave board processing, cabinet doors, wooden craft, non-paintdoors, screens, furniture, caraft window processing products, fan-shaped sculpture milling.

Advertisement Industry: Advertising signs, PVC boards, double colour boards, logo production, acrylic cutting, suck plastic molding, large word cutting, scutcheon production, crystal plates, LED / neon groove, aperture cutting, light box mould production.

 1. 12 Months warranty under normal use and lifelong maintenance we supply

 Our R-TUP company is  10 years professional manufacturer and 6 years alibaba golden supplier,specilized in cnc router machine and carving machine.

 Exhibitions and Friendly customers

Our R-TUP CNC machinery  company attends a lot of Fairs every year such as Guangzhou Interzum, Dongguan famous furniture fair, Guangzhou Wardrobe Fair etc

 Dear friends, our CNC router machine can be customized according to your requirments:

1.Motor :step motor or servo motor optional

2.Spindle :air cooling or water-cooling, :3.0kw 4.5kw or 6.0kw etc.optional

3.Guide rail :round guide rail or square linear guide optional

4.Worktable:Vacuum table,T-slot table,table size also can be customized.

etc.
