Product Overview
Description
Product Description
cow dung organic fertilizer pellet machine
Ring die pellet machine:
1.ring die & pressing roller: 1500~2000 hours
2.gearbox: 5 year warranty
3.pellet size: 6~12m
Advantage of cow dung organic fertilizer pellet machine
1. Gearbox: driving with high-precision gears, anto-matic lubricant pump system to keep the gearbox working stability.
The warranty of the gearbox are 5 years.
2. Electrical motor: vertical design for the motor, mounting hole with output as the center, equidistant distribution around,
more powerful and stability of machine working.
3. Blower system: Located in one side of work bin, free control the working time, the main function is dedusting
and discharge steam.
4. Working parts: ring-die and roller materials are alloy steel, after heat treatment, the hardness can be more than 52.
The serivice time can be 1800~2000 hours. The roller working manner is from inside to outside press, centrifugal force and extrusion pressure together, producedmore capacity. And the special design is 4-rollers working, to increase press rate. Ring-die is vertical double-deck structure. It means you can use one mould with different hole size.
Working principle of cow dung organic fertilizer pellet machine
Pellet machine is one of the biomass molding equipment.
It can make powdered biomass materials into pellets.
The starting materials for the production of pellets are pressed by the pressing roller in the matrix.
Due to the pressure and friction in the matrix, the starting materials are heated to a high temperature (nearly 60~80 °C). As a result of pressure and temprerature increasing, the materials were compressed into pellets. The output pellets will have very high strength after cooling.
Our cow dung organic fertilizer pellet machine series:
| Model No. | Power | Voltage | Output | Weight | Packing size |
| FD450 | 55KW | 380V/3 phase | 0.8~1.2t/h | 2800KG | 1.4*0.75*1.55M |
| FD560 | 90KW | 380V/3 phase | 1.5~2.0t/h | 4500KG | 1.9*0.95*1.8M |
| FD800 | 132KW | 380V/3 phase | 2.0~2.5t/h | 7000KG | 2.5*1.35*2.1M |
| FD1000 | 160KW | 380V/3 phase | 2.5~3.0t/h | 8500KG | 2.6*1.45*2.1M |
Application of cow dung organic fertilizer pellet machine
Feed pellet machine is mainly used for making animal feed pellets. Corn, bean pulp, straw, grass, rice husk, alfalfa, wheat stalk, ect. Applicable industry: aquiculture, poultry feed making plant, stock farm, poultry farm, ect.
More other pellet machine of our company
Packaging & Shipping
Packing & shipping of cow dung organic fertilizer pellet machine
Company Information
Supplier of cow dung organic fertilizer pellet machine
Wholly (China) Marketing Co., Ltd., a qualified manufacturer was founded in 2005. And it is one of the leading suppliers of biomass machine in China, and cow dung organic fertilizer pellet machine is one of our main products.
We have already sold our machines to over 60 countries, they are: Germany, France, America, England, Bulgaria, Romania, Portugal, Latvia, Russia, etc.
FAQ
Why choose us?
(1) We have produced the cow dung organic fertilizer pellet machine for more than 10 years.
(2) Our clients are all over the world, main in European.
(3) We all have passed the CE, ISO, SGS.
(4) We have better service attitude than most of Chinese suppliers.
If you have any question, feel free to contact us:
