Lace Jacquard warp knitting machine

Product Overview

Description





APPLICATION:

To produce embossed lace fabric, such a curtains, table cloth, mesh fabric and garments fabrics.





CHARACTERISTICS:

The increased jacquard bars make the ground fabric with fancy stitch effect.

Fall plate bar forms a pattern with embossed effect.

Ground guide bar, elastic guide bar and jacquard bar use electronic yarn let-off, yarn feeding is more stable and reliable.

The electronic take-up device makes changing density becomes quick and easy.

Pattern guide bars are controlled by servo motor, so the pattern range is wider and pattern changing becomes easier.





MAIN TECHNICAL SPECS:

Needle type	Compound Needle
Gauges	E18    E24
Working width	132",200"
Guide bar number	43
Main drive	Oil-immersed cam, ECCENTRIC LINKAGE (Knockover)
Speed	350-500 rpm
Pattern drive	Electronic control
Yarn let-off device	Ground guide bars: EBA electronic yarn let-off (3 sets)
Fabric take-up	Electronic take-up
Batching device	Independent batching device
Main motor power	5.5 kw  132",7.5 kw 200"
