supply various kinds carbon graphite products
- Category: >>>
- Supplier: Changsha Aobo Carbon Co. Ltd.
Share on (60248740088):
Product Overview
Description
Detail information about graphite products:
Technical parameter
Grade | Ash -specification
| Density g/cm3 | compression strength Mpa
| Flexural Strength Mpa | Resistivity μΩ·m |
G2 | 100 | 1.65 | 40 | 20 |
|
G3 | 250 | 1.55 | 25 | 14 |
|
XG-14 | 1000 | 1.72 | 45 | 25 | 18 |
XG-17 | 1000 | 1.90 | 86 | 42 | 9.5 |
Product Description
1. About material :
Aobo Carbon provide carbon brushes in all kinds of applications for OEM customers and end users. Our customers have proven the good quality can keep in long -term use. We are sure to offer you the suitable material.
Graphite material ---- for slip ring of high-speed turbine.
Metal graphite material --- for high load and low voltage motors with less commutation task.
Resin bonded graphite material--- for small and middle sized DC(Direct Current) motors and generator plant.
Electro graphite material -----has excellent commutating performance and self-lubricated functions, ha been widely
used in all AC(Alternating Current ) and DC(Direct Current) motors that achieve not only
product life but also low wear of commutator or slip ring.
2. Our products are designed to cater for:
a. Various generator plant and motor
b. Overcooled applications
c. High temperature application
3 . Detailed product description:
(1) original manufacture processing
(2)for European,American ,Korean, Japanese etc. engines
(3)high quality,design as your request
(4)competitive price
(5)secure service,delivery timely
4.Advantages of Carbon Graphite Seals
• Self lubricating
• Low coefficient of friction
• Resistance to chemicals, corrosion, and oxidation
• Dimensional stability under wide temperature variations
• Compatible with food & pharmaceuticals
• Low coefficient of thermal expansion
• Excellent thermal shock
• Good thermal conductivity
• Good mechanical strength
• Mates to a wide variety of materials
5.Typical Applications
• Corrosive environments
• Chemical pumps
• Steam joints
• Food processing pumps
• Process pumps in refineries
• Cold and hot water pumps
• Seals for agitators and mixers
• Temperatures above 400 deg F
• Cryogenic applications
Detailed Images
Packaging
FAQ
1. Why choose us ?
- Technical support - Technical people have experience in this period over 35 years.
- Material support - carbon graphite, soft graphite, electrographitic , impregnated graphite ,
Resin grapihte, metal graphite, impreganated metal graphite ,
Natural grpahite , Resin bonded .
Producing support - Using professinal machines and technological guidance .
2.Can we use our design ?
Yes, you can. After getting your detial design drawings , we do same .
3. Can we mix the different design products ?
Yes, you can modify.
4. Failure cause ?
Technical hitches | Causation | Repair |
Brush spark | 1.Commutator deformed | 1.Loosen the fastening screws to re-adjust |
2. Copper barbed or sharp edges | 2. Re-chamfer | |
3. Brush pressure is too small | 3. Adjust or replace the spring pressure | |
Brush overheating | 1. Brush too much pressure | 1. Adjust or replace the spring pressure |
2. Single Brush pressure imbalance | 2. Replacing different carbon brushes | |
Wear fast |
| 1. Clean commutator |
2. Copper barbed or sharp edges obvious | 2. Re-chamfer | |
3. Load is too small to form an oxide film | 3. Improve load or minus number of brushes | |
4.Work environment is too dry or too wet | 4.Improve the working environment or replacement brush card |
