high quality air conditioner adjustable aluminum ventilation air duct supply air grille

Construction:

• Frame: High quality extruded aluminum alloy(A6063) profile with 30mm flange


• Blade: Aerofoil blades from aluminum profile


• Blade spacing: 20mm as standard

Description:

• The frame & blades are high quality extruded aluminum profiled construction with advantages of corrosion resistance and rigidity.


• Both vertical blades and horizontal blades are available,

          SDG-AV: vertical blades,

          SDG-AH: horizontal blades

• Blades can be adjusted mannually and individually to provide air deflection in both horizontal and vertical planes.


• Maximum affective pressure areas can be achieved when the blades are positioned at 0 degree.

Surface Finish:

• Powder coated color finish as per RAL color

    standard color: RAL9016, 9010

• Natural anodized aluminum finish

Material thickness:

• Standard is 1.0mm

Foshan Vairtech Ventilation Co., Ltd is a professional manufacturer for supplying full range of ventilation products with about 15 years' experience, which is located in the Aluminum Hometown of China - Foshan City. We enjoy transportation & raw material convenience.

"Customer first, quality first" ---We are sincerely welcome you to contact us for business.
